Comparative Study of Microstructural Characteristics of P355NH Transporting Pipelines Exposed to Hydrogen

Abstract:

Pipeline transport of hydrogen offers an alternative way to move large volumes of hydrogen from production to use. One method of transport would be to use the infrastructure available for natural gas pipelines, but the specific physical and chemical properties of hydrogen and its degrading effect on metals mean that a different approach to safety considerations is required for practical implementation. Different steel grades show different responses to hydrogen exposure: some microstructures exhibit higher diffusion rates but lower hydrogen solubility, making them more susceptible to degradation. The intensity of this phenomenon depends largely on the microstructure of the steel, its alloy content, and the operating conditions. The aim of this research is to perform a comparative microstructural analysis of the P355NH steel base material and welded joints made using MIG and MIG/TIG welding technologies in pipeline sections with different histories that have been exposed to hydrogen. During the investigation, we used optical microscopic images and hardness maps showing hardness distribution to reveal the characteristics of various material structure details. The study may contribute to optimizing the safety of pipelines used for hydrogen transport and the welding technologies employed, as well as to increasing integrity under hydrogen-loaded operating conditions.

• Periodical: Advances in Science and Technology (Volume 181)
• Pages: 317-328
• DOI: https://doi.org/10.4028/p-eMZ3Mf
• Online since: August 2026
• Authors: Nóra Bencs-Nagy*, János Lukács
• Keywords: Hardness Map, Hydrogen, Microstructural Analysis, Transporting Pipelines, Welded Joint

References

[1] J. Kovács, J. Lukács, Hidrogénnel kapcsolatos károsodási módok acélcsövek esetén, Multidiszciplináris Tudományok 13 (2023) 206–223.

DOI: 10.35925/j.multi.2023.1.15

[2] G.T. Park, S.U. Koh, H.G. Jung, K.Y. Kim, Effect of microstructure on the hydrogen trapping efficiency and hydrogen induced cracking of linepipe steel, Cor. Sci. 50 (2008) 1865–1871.

DOI: 10.1016/j.corsci.2008.03.007

[3] A. Thomas, J.A. Szpunar, Hydrogen diffusion and trapping in X70 pipeline steel, Int. J. of Hydrogen Energy 45 (2019) 2390–2404.

DOI: 10.1016/j.ijhydene.2019.11.096

[4] J.F. Lessar, W.W. Gerberich, Grain size effects in Hydrogen-Assisted cracking, Metal. Trans. A 7 (1976) 953–960.

DOI: 10.1007/bf02644060

[5] V.P. Ramunni, M.I. Pascuet, N. Castin, A.M.F. Rivas, The influence of grain size on the hydrogen diffusion in bcc Fe, Comp. Mat. Sci. 188 (2020) 110146.

DOI: 10.1016/j.commatsci.2020.110146

[6] N. Yazdipour, D.P. Dunne, E.V. Pereloma, Effect of grain size on the hydrogen diffusion process in steel using cellular automaton approach, Materials Science Forum 706–709 (2012) 1568–1573.

DOI: 10.4028/www.scientific.net/msf.706-709.1568

[7] A.M. Brass, A. Chanfreau, Accelerated diffusion of hydrogen along grain boundaries in nickel, A. Mat. 44 (1996) 3823–3831.

DOI: 10.1016/1359-6454(95)00446-7

[8] R. Pourazizi, M.A. Mohtadi-Bonab, R.K.Z. Davani, J.A. Szpunar, Effect of thermo-mechanical controlled process on microstructural texture and hydrogen embrittlement resistance of API 5L X70 pipeline steels in sour environments, Int. J. of Pressure Vessels and Piping 194 (2021) 104491.

DOI: 10.1016/j.ijpvp.2021.104491

[9] W.Y. Choo, J.Y. Lee, Effect of cold working on the hydrogen trapping phenomena in pure iron, Metal. Trans. A 14 (1983) 1299–1305.

DOI: 10.1007/bf02664812

[10] A. Paul, T. Laurila, V. Vuorinen, S.V. Divinski, Thermodynamics, diffusion and the kirkendall effect in solids, Springer International Publishing, Switzerland 2014.

DOI: 10.1007/978-3-319-07461-0

[11] N. Yazdipour, A.J. Haq, K. Muzaka, E.V. Pereloma, 2D modelling of the effect of grain size on hydrogen diffusion in X70 steel, Comp. Mat. Sci. 56 (2012) 49–57.

DOI: 10.1016/j.commatsci.2012.01.003

[12] J.-L. Lee, J.-Y. Lee, The interaction of hydrogen with the interface of AI2O3 particles in iron, Metal. Trans. A 17 (1986) 2183–2186.

DOI: 10.1007/bf02645916

[13] G.-W. Hong, J.-Y. Lee, The interaction of hydrogen and the cementite-ferrite interface in carbon steel, J. of Mat. Sci. 18 (1983) 271–277.

DOI: 10.1007/bf00543835

[14] J. Lukács, A.Y. Dakhel, Full-scale Fatigue and Burst Tests on Notched Pipeline Girth Welds, under Complex Loading Conditions, A. Polytechnica Hungarica 21 (2024) 53–70.

DOI: 10.12700/aph.21.5.2024.5.5

[15] J. Lukács, Gy. Nagy, I. Harmati, F.R. Koritárné, Lné.K.Zs. Kuzsella, Selected chapters from structural integrity of engineering structures, University of Miskolc, Hungary, 2012. (In Hungarian.)
