Growth and Characterization of Tungsten Oxide for Applications in Nanoelectronics

Abstract:

Tungsten oxide nanorods were prepared in a hot filament chemical vapor deposition (HFCVD) reactor. A mixture of gases containing hydrogen, oxygen or hydrogen and methane mixed with water vapor were passed into a quartz glass jar reactor and activated using a heated tungsten filament. The resulting deposits were characterized by transmission electron microscopy (TEM), x-ray diffraction (XRD), and Raman Spectroscopy. The deposit consisted of tungsten oxide nanorods (5 – 10 nm diameter and 50 – 75 nm long) and tungsten nanospheres with diameters of ~50nm. The tungsten oxide is then reduced to metallic tungsten by annealing in a hydrogen environment.

• Periodical: Advances in Science and Technology (Volume 48)
• Pages: 113-118
• DOI: https://doi.org/10.4028/www.scientific.net/AST.48.113
• Online since: October 2006
• Authors: Karthikk Sridharan, Kenneth P. Roberts, Saibal Mitra
• Keywords: Characterization, Chemical Vapor Deposition (CVD), Nano Metal, Nano Oxide, Nanorod, Nanospheres
