The Impact of PV and WTG Integration on Transient Stability in the Meulaboh Distribution Grid

Abstract:

One of the key factors driving global interest in generating large quantities of electricity from renewable energy sources is global warming. As a consequence of advancements in solar cell fabrication, wind turbine technology, and converter technology, PV solar and Wind Turbine Generators (WTG) have emerged as the most promising renewable energy sources for large-scale electricity generation. If the current commissioning rate continues, the capacity of PV and Wind Turbine Generators will necessitate modifications to various aspects of the power system and may impact system stability. This research broadly examines technical challenges, particularly transient stability issues, associated with the large-scale integration of PV and Wind Turbine Generators into the power system. Furthermore, this research also reviews dynamic models by applying three-phase short-circuit connections at critical network points and observes their influence on transient stability of the system. Simulations are conducted using ETAP 19.0 software, which was employed to model the 20 kV distribution system network (Lamno and Calang) from the Main Substation of Muelaboh City Area. Finally, this paper summarizes research findings regarding techniques and solutions to address transient stability issues in the electric power system associated with the large-scale integration of PV and WTG into the distribution system.

• Periodical: Construction Technologies and Architecture (Volume 14)
• Pages: 79-86
• DOI: https://doi.org/10.4028/p-P0eRzD
• Online since: August 2024
• Authors: Robi Kurniawan, Muhammad Daud*, Arnawan Hasibuan, Mukhlis Abd. Muthalib, Adi Setiawan, Nelly Safitri
• Keywords: Software Etap, Solar PV, Wind Turbine Generators
