Shear Strengthening Behavior of Reinforced Concrete Beams with Varying Blot Spacing and Wire Mesh Presence in Geopolymer Mortar Panels

Abstract:

This study aims to analyzes the shear behavior, crack patterns, and failure modes of reinforced concrete beams strengthened with geopolymer mortar panels (GMP) which consisted PVA fibers and wire mesh with varying bolts spacing. Shear behavior is discussed based on load-deflection behavior, maximum load, steel load strain, and concrete load strain. The research stages were divided into two, namely compressive strength of geopolymer mortar and shear test of reinforced concrete beams. The geopolymer mortar compressive strength test used 50x50x50 mm cube samples, tested at 3, 7, and 28 days. The geopolymer mortar was produced from fly ash as the base material and activators, such as sodium hydroxide and sodium silicate. Meanwhile, the beam shear test have cross section of 150x300 mm with a length of 2300 mm. There were four variation, namely CB, GM-W-200, GM-W-300, and GM-NW-200 beams. The results showed that adding reinforcement panels with geopolymer mortar material which consisted PVA fibers and wire mesh with distance of 200 mm (GM-W-200) affected the behavior of reinforced concrete beams to become more ductile and no longer occur shear collapse. Meanwhile, GM-W-300 and GM-NW-200 beams have not improved the bending behavior of the beams, and shear failure still occur as in CB beams.

• Periodical: Construction Technologies and Architecture (Volume 19)
• Pages: 93-102
• DOI: https://doi.org/10.4028/p-Yys7nD
• Online since: June 2025
• Authors: Muh. Afwan Irsyad*, Rita Irmawaty, Fakhruddin Fakhruddin
• Keywords: Geopolymer Mortar Panel (GMP), PVA Fiber, Reinforced Concrete (RC) Beam, Shear Reinforcement

References

[1] Fakhruddin, Irmawaty. R, Putri. J.J.E, "External Shear Stregthening of RC Beams with Anchored Geopolymer Fiber Mortal Panel: An Experimental Study" Materials Science Forum - Q4 Journal., vol. 1091, pp.93-100, June 2023.

DOI: 10.4028/p-1tdbui

[2] M. Al-Bazoon, A. Jaafer, H. Haidar, and A. Dawood, "Shear Strengthening of Reinforced Concrete Beam Using Wire Mesh–Epoxy Composite," Civ. Eng. J., vol. 8, no. 6, p.1205–1226, 2022.

DOI: 10.28991/CEJ-2022-08-06-09

[3] M. F. Ojaimi, "Experimental study on shear strengthening of reinforced concrete beams," Tongji Daxue Xuebao/Journal Tongji Univ., vol. 21, no. 2, p.53–61, 2021.

[4] J. Matsimbe, M. Dinka, D. Olukanni, and I. Musonda, "Geopolymer: A Systematic Review of Methodologies," Materials (Basel)., vol. 15, no. 19, 2022.

DOI: 10.3390/ma15196852

[5] P. Cong and Y. Cheng, "Advances in geopolymer materials: A comprehensive review," J. Traffic Transp. Eng. (English Ed., vol. 8, no. 3, p.283–314, 2021.

DOI: 10.1016/j.jtte.2021.03.004

[6] P. Ghadir, M. Zamanian, N. Mahbubi-Motlagh, M. Saberian, J. Li, and N. Ranjbar, "Shear strength and life cycle assessment of volcanic ash-based geopolymer and cement stabilized soil: A comparative study," Transp. Geotech., vol. 31, no. April, p.100639, 2021.

DOI: 10.1016/j.trgeo.2021.100639

[7] Herwani, I. Imran, B. Budiono, and E. Zulkifli, "Strength Enhancement, Ductility, and Confinement Effectiveness Index of Fly Ash-based Geopolymer Concrete Square Columns," J. Eng. Technol. Sci., vol. 54, no. 4, 2022.

DOI: 10.5614/j.eng.technol.sci.2022.54.4.11

[8] E. F. I. Permata and A. Wardhono, "Effect Of Activator Solution Strength On Geopolymer Mortar Based On Flying Soil And 12 Molar Naoh At Ss/Sh Conditions 2.0 And 4.0," Rekayasa Tek. Sipil, vol. 1, no. 1, 2019.

[9] M. Amran, S. Debbarma, and T. Ozbakkaloglu, "Fly ash-based eco-friendly geopolymer concrete: A critical review of the long-term durability properties," Constr. Build. Mater., vol. 270, p.121857, 2021.

DOI: 10.1016/j.conbuildmat.2020.121857

[10] C. Suksiripattanapong, S. Horpibulsuk, C. Yeanyong, and A. Arulrajah, "Evaluation of polyvinyl alcohol and high calcium fly ash based geopolymer for the improvement of soft Bangkok clay," Transp. Geotech., vol. 27, p.100476, 2021.

DOI: 10.1016/j.trgeo.2020.100476

[11] Ekaputri, Fujiyama, Chijiwa, Ho, and Nguyen, "Improving Geopolymer Characteristics with Addition of Poly-Vinyl Alcohol ( PVA ) Fibers," Civ. Eng. Dimens., vol. 23, no. 1, p.28–34, 2021.

DOI: 10.9744/CED.23.1.28-34

[12] Multasam. M, Irmawaty. R, Fakhruddin.F, "Flexural Behavior of Reinforced Concrete Beams Repaired Using Geopolymer Fiber Mortar" Lowland Technology International, vol. 24-1, pp.20-25, 2022.

[13] Irmawaty. R, Fakhruddin, Ekaputri. J.J, "Experimental and Analytical Study For Shear Strengthening of Reinforced-Concrete Beams Using A Prefabricated Geopolymer-Mortal Panel" Case Studies in Construction Materials (Elsevier)-Q1 Jounal, vol. 17, December 2022.

DOI: 10.1016/j.cscm.2022.e01568

[14] SNI 2052, "Baja tulangan beton," Badan Stand. Nas. Indones., 2014.

[15] ASTM E8/E8M-09, "Standard Test Methods for Tension Testing of Metallic Materials," Am. Stand. Test. Mater., no. C, p.1–27, 2010.
