Axisymmetric Bending of Circular Plates on a Variable Elastic Base

Abstract:

An algorithm of direct integration method for calculation of annular plates lying on elastic Winkler base with variable bedding coefficient under the action of transverse load is proposed. To verify the results obtained by the proposed method, the finite element method implemented in PC LIRA-SAPR is used. Two examples of calculations are considered. Analysis of the results shows that the values of deflections practically coincide in calculations of a circular plate by the author's method and by the finite-element method, and discrepancy between the values of bending moments reaches 9.3 %. Moreover, the discrepancy in deflections appears only in the fourth (and sometimes even in the fifth) decimal place. It is noted that the method of direct integration has demonstrated very high accuracy in solving numerous problems of deformable solid mechanics that have exact solutions. The discrepancy in the values of bending moments obtained here is related to the semi-automatic breakdown of the finite-element mesh in PC LIRA-SAPR. This statement is based on the fact that when the mesh is thickened in the circumferential direction, the results obtained by the two methods in determining the radial and circumferential bending moments converge considerably.

• Periodical: Construction Technologies and Architecture (Volume 9)
• Pages: 3-10
• DOI: https://doi.org/10.4028/p-L9yr2n
• Online since: August 2023
• Authors: Mykola Surianinov*, Yurii Krutii, Oleksiy Klymenko, Vladyslav Vakulenko, Serhii Rudakov
• Keywords: Annular Plate, Elastic Base, Finite Element Method, Fuss-Winkler Model, LIRA-CAD, Variable Bedding Factor

References

[1] Simvulidi I. A. Calculation of engineering structures on an elastic foundation. Ed. 3rd, rev. and additional Textbook for universities. M.: Vy`ssh. Shkola, (1973) 431.

[2] Zienkiewich O. C., Taylor R. L. The Finite Element Method for Solid and Structural Mechanics. Oxford: Butterworth-Heinemann, (2005) 736.

[3] Kaddari M., Kaci A., Bousahla A. A., Tounsi A., Bourada F., Tounsi A., Al-Osta M. A. A study on the structural behaviour of functionally graded porous plates on elastic foundation using a new quasi-3D model: Bending and free vibration analysis. Computers and Concrete, 25(1) (2020) 37–57.

DOI: 10.1142/s0219455424501177

[4] Huang Y., Li X.-F. Effect of radial reaction force on the bending of circular plates resting on a ring support. International Journal of Mechanical Sciences, 119 (2016) 197–207.

DOI: 10.1016/j.ijmecsci.2016.10.014

[5] Salawu S. A., Sobamowo G. M., Sadiq, O. M. Investigation of dynamic behaviour of circular plates resting on Winkler and Pasternak foundations. SN Appl. Sci., 1, 1588 (2019).

DOI: 10.1007/s42452-019-1588-8

[6] Bosakov S.V. On the solution of a non-axisymmetric contact problem for a round plate. Vestnyk Brestskoho hosudarstvennoho tekhnycheskoho unyversyteta, Brest, 1 (85) (2014) 83-87.

[7] Bosakov S.V. To the calculation of rectangular slabs on an elastic foundation. Vestnik BNTU, 5 (2007) 5–10.

[8] Czejtlin A. I. Applied Methods for Solving Boundary Problems of Structural Mechanics. M.: Strojizdat (1984) 334.

[9] Bosakov S. V. The Ritz Method in Contact Problems of the Theory of Elasticity. Brest (2006) 108.

[10] Krutii Yu. S. Development of the method of solving the problems of stability and cracking of deformable systems with changing non-permanent parameters. » dys… d-ra. tekhn. nauk: 01.02.04 Odesa (2016) 272.

[11] Krutii Y.S., Surianinov M.G., Karnaukhova G.S. «Calculation Method for Axisymmetric Bending of Circular and Annular Plates on a Changeable Elastic Bed, Part 1. Analytical Relations», Strength of Materials, Vol. 53(2), p.247–257, 2021.

DOI: 10.1007/s11223-021-00282-2

[12] Krutii Yu. S., Surianinov M. G. Exact Solution of the Differential Equation for the Stability of the Equilibrium of an Elastic Rod with an Arbitrary Continuous Variable Stiffness. Vi`snik KNUTD, 1 (94) (2016) 72–84.

[13] Horodetskyi D. A., Barabash M. S., Vodopianov R. Iu. Prohrammnyi kompleks LYRA-SAPR 2015, Uchebnoe posobye; pod red. akademyka RAASN A. S. Horodetskoho, M., (2015).

[14] Shvab'yuk, V. I., Krutii, Y. S., Surianinov M. G. Investigation of the Free Vibrations of Bar Elements with Variable Parameters Using the Direct Integration Method. Strength of MaterialsVolume, 48(3) (2016) 384–393.

DOI: 10.1007/s11223-016-9776-x

[15] Krutii Yu., Surianinov M., Vandynskyi V. Analytic Formulas for the Cantilever Structures' Natural Frequencies with Taking into Account the Dead Weight. Materials Science Forum, 968 (2019) 450-459.

DOI: 10.4028/www.scientific.net/msf.968.450
