Laser Implantation of Niobium and Titanium-Based Particles on Hot Working Tool Surfaces for Improving the Tribological Performance within Hot Stamping

Abstract:

Within the scope of this work, a new approach named laser implantation process has been investigated, in order to improve the tribological performance of hot stamping tools. This surface engineering technology enables the generation of dome-shaped, elevated and highly wear resistant microfeatures on tool surfaces in consequence of a localized dispersing of hard ceramic particles via pulsed laser radiation. As a result, the topography and material properties of the tool and thus the tribological interactions at the blank-die interface are locally influenced. However, a suitable selection of hard ceramic particles is imperative for generating defect-free surface features with a high share of homogenously disturbed particles. For this purpose, different niobium (NbB₂ and NbC) as well as titanium-based (TiB₂ and TiC) materials were embedded on hot working tool specimens and subsequently analyzed with regard to their resulting shape and mechanical properties. Afterwards, modified pin-on-disk tests were carried out by using conventional and laser-implanted tool surfaces, in order to evaluate the wear and friction behavior of both tooling systems.

• Periodical: Defect and Diffusion Forum (Volume 404)
• Pages: 117-123
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.404.117
• Online since: October 2020
• Authors: Stephan Schirdewahn*, Felix Spranger, Kai Hilgenberg, Marion Merklein
• Keywords: Laser Implantation, Surface Modification, Tribology

References

[1] R. Neugebauer, T. Altan, M. Geiger, M. Kleiner, A. Sterzinger, Sheet metal forming at elevated temperatures, CIRP Annals 55 (2006) 793-816.

DOI: 10.1016/j.cirp.2006.10.008

[2] H. Karbasian, A.E. Tekkaya, A review on hot stamping, Journal of Materials Processing Technology 210 (2010) 2103–2118.

DOI: 10.1016/j.jmatprotec.2010.07.019

[3] L. Pelcastre, Hot forming tribology: Galling of tools and associated problems, 1st ed., Universitetstryckeriet, Luleå, (2011).

[4] A. Shihomatsu, S. T. Button, T. B. da Silva, Tribological Behavior of Laser Textured Hot Stamping Dies, Advances in Tribology (2016) 1-15.

DOI: 10.1155/2016/8106410

[5] F. Spranger, M. Lopes, S. Schirdewahn, J. Degner, M. Merklein, K. Hilgenberg, Microstructural evolution and geometrical properties of TiB2 metal matrix composite protrusions on hot work tool steel surfaces manufactured by laser implantation, The International Journal of Advanced Manufacturing Technology 106 (2020) 481-501.

DOI: 10.1007/s00170-019-04630-0

[6] F. Klocke, Manufacturing Processes 4, first ed., Springer-Verlage, Aachen, (2013).
