Fatigue Strength and Wear Behavior of NCD and MLD Diamond Coatings Characterized by Different Level of Residual Stresses after Annealing

Abstract:

Nano-composite (NCD) and multi-layered (MLD) diamond coatings deposited on cemented carbide tools are often applied in machining of non-ferrous materials. A critical issue for their wear behavior, especially in cutting processes in which interrupted repetitive loads are applied such as milling, is the fatigue strength. The latter parameter is significantly affected by the level of residual stresses in their diamond film structure. For investigating such an issue, untreated as well as annealed for 8h vacuum NCD and MLD coatings of the same thicknesses were produced. Inclined impact tests supported by appropriate FEA models were conducted for calculating the level of the residual stresses and for determining the critical impact force for the fatigue damage after 10⁶ impacts. Moreover, the wear behavior of diamond coated inserts was investigating in milling aluminum foam. According to the attained results, the reduction of the residual stresses in the diamond film structure contributes to a significant increase of the fatigue strength and coated tool life for both examined cases. Moreover, due to the enhanced tribological properties of NCD films, an improved wear behavior is registered compared to the MLD ones, when both coatings possess the same level of residual stresses.

• Periodical: Defect and Diffusion Forum (Volume 404)
• Pages: 39-44
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.404.39
• Online since: October 2020
• Authors: G. Skordaris*, Tilemachos Kotsanis, Apostolos Boumpakis, Fani Stergioudi
• Keywords: Diamond Coatings, Fatigue, Wear

References

[1] R. Haubner, W. Kalss, Diamond deposition on hardmetal substrates - Comparison of substrate pre-treatments and industrial applications, INT J REFRACT MET H. 28 (2010) 475–483.

DOI: 10.1016/j.ijrmhm.2010.03.004

[2] E.-G. Ng, D. Szablewski, M. Dumitrescu, M.A. Elbestawi, J.H. Sokolowski, High Speed Face Milling of a Aluminium Silicon Alloy Casting, CIRP ANN-MANUF TECHN. 53 (2004) 69-72.

DOI: 10.1016/s0007-8506(07)60647-7

[3] R. Polini, Chemically vapour deposited diamond coatings on cemented tungsten carbides: Substrate pretreatments, adhesion and cutting performance, Thin Solid Films. 515 (2006) 4 – 13.

DOI: 10.1016/j.tsf.2005.12.042

[4] G. Skordaris, K.-D. Bouzakis, P. Charalampous, T. Kotsanis, E. Bouzakis, O. Lemmer, Effect of structure and residual stresses of diamond coated cemented carbide tools on the film adhesion and developed wear mechanisms in milling, CIRP ANN-MANUF TECHN. 65 (2016) 101-104.

DOI: 10.1016/j.cirp.2016.04.007

[5] R. Dumpala, N. Kumar, C.R. Kumaran, S. Dash, B. Ramamoorthy, M.S. Ramachandra Rao, Adhesion Characteristics of Nano- and Micro-crystal-line Diamond Coatings: Raman Stress Mapping of the Scratch Tracks, Diam. Relat. Mater. 44 (2014) 71–77.

DOI: 10.1016/j.diamond.2014.02.007

[6] R. Dumpala, M. Chandran, N. Kumar, S. Dash, B. Ramamoorthy, M.S. Ramachandra Rao, Growth and Characterization of Integrated Nano- and Microcrystalline Dual Layer Composite Diamond Coatings on WC–Co Substrates, INT J REFRACT MET H. 37 (2013) 127–133.

DOI: 10.1016/j.ijrmhm.2012.11.007

[7] M.A. Fraga, A. Contin, L.A.A. Rodríguez, J. Vieira, R.A. Campos, E.J. Corat, V.J. Trava Airoldi, Nano- and Microcrystalline Diamond Deposition on Pretreated WC–Co Substrates: Structural Properties and Adhesion, Mater. Res. Express. 3(2) (2016) 025601.

DOI: 10.1088/2053-1591/3/2/025601

[8] N. Woehrl, T. Hirte, O. Posth, V. Buck, Investigation of the coefficient of thermal expansion in nanocrystalline diamond films, Diam. Relat. Mater. 18 (2009) 224–228.

DOI: 10.1016/j.diamond.2008.10.016

[9] M. H. Staia, M. D'Alessandria, D. T. Quinto, F. Roudet, M. Marsal Astort, High-temperature tribological characterization of commercial TiAlN coatings, J. Phys.: Condens. Matter. 18 (2006) 1727–1736.

DOI: 10.1088/0953-8984/18/32/s04

[10] Available online: www.impact-bz.com.

[11] G. Skordaris, F. Stergioudi, A. Boumpakis, D. Stergioudi, A FEA-based methodology to predict the osteotome wear status during nasal bone surgical operations, Coatings. 9 (2019) 855.

DOI: 10.3390/coatings9120855

[12] K.-D. Bouzakis, G. Skordaris, E. Bouzakis, S. Makrimallakis, S. Kombogiannis, O. Lemmer, Fatigue strength of diamond coatings' interface assessed by inclined impact test, Surf. Coat. Technol. 237 (2013) 135-141.

DOI: 10.1016/j.surfcoat.2013.09.030
