Energy and Exergy Analysis of Vapor Compression Refrigeration System with Integrated Mechanical Subcooling Using R134a, R450a, R513a, and R515a

Abstract:

This study compares the performance of a vapor compression refrigeration system (VCRS) with an integrated mechanical subcooled vapor compression refrigeration system (IMS-VCRS) in water-cooled centrifugal chillers. Specifically, this study uses four different refrigerants R134a, R450a, R513a, and R515a. A mathematical model of IMS-VCRS is developed to determine the performance parameters at a fixed cooling capacity of 1750 kW. This study investigates that the energy consumption of an IMS-VCRS is reduced by 11.36% for R134a, 11.98% for R450a, 13.36% for R513a, and 11.89% for R515a. The mechanical subcooled system's COP is increased by 12.84% for R134a, 13.59% for R450a, 15.40% for R513a, and 13.48% for R515a due to the low power requirement. In addition, exergetic analysis is also used to determine the system's second law efficiencies, which in this study improved by 11.25%, 11.84%, 13.41%, and 11.77% for R134a, R450a, R513a, and R515a respectively. Furthermore, parametric analyses were performed to investigate the effects of various system parameters such as evaporator and condenser temperatures.

• Periodical: Engineering Headway (Volume 26)
• Pages: 89-102
• DOI: https://doi.org/10.4028/p-iA207G
• Online since: August 2025
• Authors: Kunal Singh, Naveen Solanki*, Dheeraj Joshi, Diptanshu Chowdhury, Vaibhav Jain
• Keywords: COP, Energy, Exergy, Mechanical Subcooling, Second-Law Efficiency

References

[1] J. W., Thornton, S. A., Klein, and J. W., Mitchell, "Dedicated mechanical-subcooling design strategies for supermarket applications," Int. J. Refrig. 1994;17(8):508–15.

DOI: 10.1016/0140-7007(94)90026-4

[2] G. Li, "Performance evaluation of low global warming potential working fluids as R134a alternatives for two-stage centrifugal chiller applications," Korean Journal of Chemical Engineering, vol. 38, no. 7, p.1438–1451, Jul. 2021.

DOI: 10.1007/s11814-021-0785-5

[3] A. Mota-Babiloni, J. Navarro-Esbrí, A. Barragán-Cervera, F. Molés, and B. Peris, "Drop-in analysis of an internal heat exchanger in a vapour compression system using R1234ze(E) and R450A as alternatives for R134a," Energy, vol. 90, p.1636–1644, 2015.

DOI: 10.1016/j.energy.2015.06.133

[4] R. Llopis, D. Sánchez, R. Cabello, J. Catalán-Gil, and L. Nebot-Andrés, "Experimental analysis of R-450A and R-513A as replacements of R-134a and R-507A in a medium temperature commercial refrigeration system."

DOI: 10.1016/j.ijrefrig.2017.08.022

[5] V. Bahel, and S. M., Zubair, "Mechanical-subcooling improves supermarket refrigeration performance,"Heat-Piping-Air Cond 1988;60:105–7

[6] S. M., Zubair, M. Yaqub, and S. H. Khan, "Second-law-based thermodynamic analysis of two-stage and mechanical-subcooling refrigeration cycles." Int J Refrig 1996;19:506–16.

DOI: 10.1016/s0140-7007(96)00045-x

[7] J. R. Khan, and S. M., Zubair, " Design and rating of integrated mechanical-sub-cooling vapor-compression refrigeration system,"Energy Conversion and Management, 2000, Vol. 41, No. 11, p.1201–1222.

DOI: 10.1016/s0196-8904(99)00169-7

[8] S. M., Zubair,"Thermodynamics of a vapor-compression refrigeration cycle with mechanical sub-cooling," Energy, Vol. 19, No. 6, p.707–715.

DOI: 10.1016/0360-5442(94)90009-4

[9] S. M., Zubair,"Improvement of refrigeration/air-conditioning performance with mechanical sub-cooling," Energy Vol. 15, No. 5, p.427–433.

DOI: 10.1016/0360-5442(90)90039-5

[10] S. Goktun, "An overview of chlorine-free refrigerants for centrifugal chillers," Energy, Vol. 20, No. 9, p.937–940, 1995.

DOI: 10.1016/0360-5442(95)00009-6

[11] S. M. Zubair, "Thermodynamics of a vapor-compression refrigeration cycle with mechanical subcooling," 1994.

DOI: 10.1016/0360-5442(94)90009-4

[12] J. U. R. Khan and S. M. Zubair, "Design and rating of an integrated mechanical-subcooling vapor-compression refrigeration system," 2000.

DOI: 10.1016/s0196-8904(99)00169-7

[13] S. Panneerselvam, P. Thangavel, and S. Kannaki, "Performance analysis of vapour compression refrigeration system with mechanical subcooling," Int. J. Innov. Technol. Explor. Eng., vol. 8, no. 8, p.1061–1064, 2019.

[14] A., Klein, 2018. Engineering Equation Solver, Professional Version 10.561, F-Chart Software, Madison, WI 53744.

[15] A.S. Dalkilic and S. Wongwises, "A performance comparison of vapour-compression refrigeration system using various alternative refrigerants," International Communications in Heat and Mass Transfer, vol. 37, no. 9, p.1340–1349, Nov. 2010, doi: 10.1016/j.icheatmasstransfer. 2010.07.006.

DOI: 10.1016/j.icheatmasstransfer.2010.07.006
