Comparative Flexural Analysis of Cantilever Beam at Various Loads Using Analytical, Computational and Experimental Techniques

Abstract:

Measurement of strain and stress plays a crucial role in advancing research in mechanical engineering. In this paper, the bending strain and stress of the steel cantilever beam subjected to concentrated loads at the free end are investigated using analytical, experimental, and numerical approaches. The experimental investigation was carried out through the use of a strain gauge sensor connected with a Wheatstone quarter-bridge configuration. The strain gauge used in this experiment is interfaced with the NI SignalExpress software in conjunction with the NI modules to ensure accurate data acquisition. The experimental measurements provide essential benchmark values for comparison with the numerical results. The numerical simulation is developed using ANSYS Workbench. The comparison results show that the experimental values have good agreement with the simulated FEM and analytical values. The findings of this study provide valuable insights into the bending strain characteristics of steel cantilever beams and contribute to the advancement of mechanical engineering research.

• Periodical: Engineering Headway (Volume 4)
• Pages: 35-44
• DOI: https://doi.org/10.4028/p-z1H6nq
• Online since: March 2024
• Authors: Ashenafi Abuye*, Fasikaw Kibrete, Getaw Ayay, Ermias Gebrekidan
• Keywords: Bending Strain, Cantilever Beam, Strain Gauge

References

[1] A. L. Silva, M. Varanis, A. G. Mereles, C. Oliveira, and J. M. Balthazar, "A study of strain and deformation measurement using the Arduino microcontroller and strain gauges devices," Rev. Bras. Ensino Fis., vol. 41, no. 3, 2019.

DOI: 10.1590/1806-9126-RBEF-2018-0206

[2] S. V. Gaikar and N. N. Deshmukh, "Effect of excitation voltage and lead wire resistance on strain measurement," 2017 2nd Int. Conf. Converg. Technol. I2CT 2017, vol. 2017-Janua, p.747–752, 2017.

DOI: 10.1109/I2CT.2017.8226228

[3] L. D. V. Anand, D. Hepsiba, S. Palaniappan, B. Sumathy, P. Vijayakumar, and S. S. Rani, "Automatic strain sensing measurement on steel beam using strain gauge," Mater. Today Proc., vol. 45, p.2578–2580, 2021.

DOI: 10.1016/j.matpr.2020.11.274

[4] A. Silva, M. Varanis, and A. G. Mereles, "A consistent experimental approach for strain measurement: Two case studies," Proc. XXXVIII Iber. Lat. Am. Congr. Comput. Methods Eng., no. November, 2017.

DOI: 10.20906/cps/cilamce2017-0718

[5] A. C. Mitra, A. Jagtap, and S. Kachare, "Development and Validation of Experimental Setup for Flexural Formula of Cantilever Beam Using NI-LabVIEW," Mater. Today Proc., vol. 5, no. 9, p.20326–20335, 2018.

DOI: 10.1016/j.matpr.2018.06.407

[6] L. Esquivel Villegas, D. R. Quintero Barrientos, J. A. Diosdado De la Peña, A. de J. Balvantín García, and P. A. Limon Leyva, "Integration of Numerical, Theoretical & Experimental Methods for the Calculation and Measurement of Strains in an Experimental Stress Analysis Lecture," Exp. Tech., vol. 42, no. 3, p.333–342, 2018.

DOI: 10.1007/s40799-018-0232-7
