Authors: Shu Yuan Zhang, Yun Xin Wu

Abstract: A mathematical model has been developed to predict the residual stresses level in pre-stretched aluminum alloy plate. This is based on force balances of the residual stress, theory of plastoelasticity and a new conception of free length. The model is relatively simple because only rolling direction residual stress is taken into account, but provides a clear illustration of stress relief mechanism in stretching process. With this model, residual stress distributions of stretched beam can be determined directly by knowing the specimen dimensions, material properties and the original stress. The model offers an useful tool to show the effect of varying tension ratio on the final residual stress level, thus makes it possible to predict stress relief and control residual stresses. An example of using the model is presented by applying published data while showing mechanism of stress relief during stretching. Analysis indicates that it is stretch-caused convergence of the free lengths of strips in beam that lead to reduction in the residual stresses.

3187

Authors: Jing Yan, Ya Wu Zeng, Rui Gao

Abstract: For the research of beam’s deformation, material mechanics uses equation of small deflection curve which neglects 1^{st}^{ }order derivative of deflection and regards bending moment M is merely a function of abscissa x, and then gets the approximate solution of vertical displacement. However in some case, small deflection curve isn’t efficacious, so two methods come up in this paper to solve the accurate differential equation of beam’s deformation. This paper takes a slightness beam from temperature controlling device as an example and shows detailed process of mathematical modeling and solving. For iteration, firstly governing equations are founded, then an initial value is put into it to work out a new value, next see the new value as a new initial value and calculate again, by doing the operation repeatedly steady-state solution will be got in the end. For functional analysis, deflection equation is assumed as a kind of function containing some undetermined coefficients, then make it satisfy all the boundary conditions, and establish residual fonctionelle, by partial derivative operation to make the fonctionelle minimum, undetermined coefficients are estimated and deflection curve is got. At the end, impacts of gravity and axial deformation are discussed.

6144

Authors: Zhi Ping Yin, Jiong Zhang, Jin Guo, Qi Qing Huang

Abstract: The finite element software ANSYS was employed to create a finite element model of the cracked wing beam integrated structure, and the stress field of the crack tip was got by the material nonlinearity (elastic-plastic) analysis method. Based on the maximum tensile stress theory criteria, the crack deflection angle was obtained. The crack deflection angles with different geometry parameters (crack length, wed thickness, the height-thickness ratio of the stringer, cross-sectional area, and the location of the stringer) of the wing beam integrated structure were calculated and compared with each other. So the influences of the geometry parameters of the wing beam integrated structure on the crack deflection were studied. The crack deflection angles obtained in elastic analyzing and elastic-plastic analyzing were compared to investigate the effects of the material property on the crack deflection angle.

101

Authors: Qiong Fen Wang, Yuan Cai Liu, Liang Cao, Ji Yao, Jian Feng Huang

Abstract: Calculations of the end-plate semi-rigid joints are carried out with a FE-program ANSYS. Some results of the calculations are introduced in this paper. The influences of the joints semi-rigidity on the deformation, the bending capacity and the internal force of the structure are researched; the initial rotational stiffness, the elastic ultimate moment and the plastic ultimate moment of the steel joints and the composite joints are compared. Some results may be useful for the design of the end-plate semi-rigid joints.

1625

Abstract: The equation of large deflection of functionally graded beam subjected to arbitrary loading condition is derived. In this work assumed that the elastic modulus varies by exponential and power function in longitudinal direction. The nonlinear derived equation has not exact solution so shooting method has been proposed to solve the nonlinear equation of large deflection. Results are validated with finite element solutions. The method will be useful toward the design of compliant mechanisms driven by smart actuators. Finally the effect of different elastic modulus functions and loading conditions are investigated and discussed.

4705
