Preparation of PMZN Piezoceramic Using Sol-Autocombustion Synthesized PZT Powder as a Base

Abstract:

Using Zr(NO3)4.5H2O as Zr source, PZT powder with a single-phase perovskite structure was synthesized by a sol-autocombustion method at a calcining temperature of 700°C. Compared with a solid-state reaction method, the calcining temperature of PZT can be lowered by 200°C when using the sol-autocombustion method. PMZN ceramic was prepared at a sintering temperature of 1050°C with the resulting PZT powder as a base, which can lower the sintering temperature by 150°C. The microstructure of the PMZN ceramic was investigated by XRD and SEM, and the dielectric and piezoelectric properties were measured. The results showed that the PMZN piezoelectric ceramic has a tetragonal perovskite structure, showing the main electrical properties as follows: Kp = 0.54, Qm = 1073, tgd £ 0.001, e33 T/ e0 = 1236, d33 = 454pC/N, and fs =136.1KHz.

• Periodical: Key Engineering Materials (Volumes 280-283)
• Pages: 219-222
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.280-283.219
• Online since: February 2007
• Authors: Hua Jun Sun, Wen Chen, Qing Xu, Jing Zhou, Xiao Fang Liu
• Keywords: Curie Temperature, Piezoelectric Ceramic (PZT), PMZN, Sol-Autocombustion Method

References

[1] F. Levassort, P. Tran-Huu-Hue and M. Lethiecq: J. Eur. Ceram. Soc. Vol. 21 (2001), p.1361.

[2] H.Y. Guo, J.B. Xu and W. L. Zhong: Solid States Comm. Vol. 121 (2002), p.603.

[3] L.B. Kong, W. Zhu and O.K. Tan: Mater. Lett. Vol. 40 (2000), p.232.

[4] J.T. Wang and F. Tang: Mater. Chem. Phys. Vol. 75 (2002), p.86.

[5] N. Yasuda, H. Ohwa and Y. Ishibashi: Jpn. J. Appl. Phys. Vol. 40 (2001), p.5664.

[6] Y. Gao, Y.H. Chen and D. Viehl: Jpn. J. Appl. Phys. Vol. 40 (2001), p.687.

[7] J. Zhou, W. Chen and Q. Xu: Piezoelectric & Acoustooptics Vol. 24 (2002), p.43.

[8] J. Zhou, W. Chen and Q. Xu: Piezoelectric & Acoustooptics Vol. 23 (2001), p.31.

[9] Z. Yue, J. Zhou and L. Li: J. Mater. Res. Vol. 13 (1999), p.483.

[10] M. Zhang, X. He and Shanyi Du: Piezoelectric & Acoustooptics Vol. 22 (2000), p.190.
