Time Series Analysis for the Mechanical Lapping of Single Crystal Diamond Cutting Tools

Abstract:

In order to avoid the stochastic damage of micro cleavage on cutting edge, a brittle-ductile transition lapping mechanism is proposed for the mechanical lapping of single crystal diamond cutting tools to direct the tools lapping. As expected, the critical depths of cut for brittle-ductile transition in different orientations and on different crystal planes are calculated. According to the theoretical results, the actual dynamic depth of cut is controlled within the critical depth of cut, which ensures that the tool lapping is carried out in ductile regime and the changes of cutting edge radius characterize with some specific time laws in lapping. Therefore, the time series and nonlinear least square methods are used to analyze the changing laws of cutting edge radius. As a result, a coupled model to build a bridge between the cutting edge radius changes and lapping time is developed. In terms of this developed model, a required cutting edge radius restricts a tool’s lapping time. Above all, the cutting edge radius is known in advance and has no needs measuring. So the production efficiency of diamond cutting tools is improved and its production cost is reduced accordingly.

• Periodical: Key Engineering Materials (Volumes 291-292)
• Pages: 331-336
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.291-292.331
• Online since: August 2005
• Authors: Wen Jun Zong, Dan Li, H.X. Wang, T. Sun, K. Cheng, Ming Jun Chen
• Keywords: Cutting Edge Radius, Diamond Cutting Tool, Mechanical Lapping, Time Series Analysis

References

[1] Z. J. Yuan, Y. X. Yao, M. Zhou, et al: Annals of the CIRP, Vol. 52 (2003), No. 1, pp.285-288.

[2] A. P. Malshe, B. S. Park, W. D. Brown, et al: Diamond and Related Materials, Vol. 8 (1999), pp.1198-1213.

[3] A. Asai, Y. Taguchi, K. Horio, et al: Annals of the CIRP, Vol. 39 (1990), No. 1, pp.85-88.

[4] A. Lucca, Y. W. Seo, R Komanduri: Annals of the CIRP, Vol. 42 (1993), No. 1, pp.83-86.

[5] X. P. Li, M. Rahman, K. Liu, et al: Journal of Materials Processing Technology, Vol. 140 (2003), pp.358-362.

[6] S. M. Wu, S. G. Kapoo: SME Technical Paper, (1979), pp. M579-M171.

[7] J. E. Field, C. S. J. Pickles: Diamond and Related Materials, Vol. 5 (1996), pp.625-634.

[8] W.J. Zong, D. Li, K. Cheng, et al: International Journal of Machine Tools and Manufacture, Vol. 45 (2005), pp.783-788.

[9] R. H. Telling, C. J. Pickard, M. C. Payne, et al: Physical Review Letters, Vol. 84 (2000), No. 22, pp.5160-5163.
