Research on Highly Efficient EDM Pulse Power Supply and Its Experiments

Abstract:

Their efficiency and their power factor of conventional independent electrical discharge machining (EDM) pulse power supplies with the current-limiting-resistor circuit is so low that they do not meet the need of advanced EDM technologies. The design of highly efficient EDM pulse power supply based on switching circuit pulse width modulation current closed-loop principle has been initiated. It is composed of such three stages as a single-phase active power factor correction preregulator, a full-bridge phase shift resonant converter based on machining current closed-loop control and a pulse generator based on machining sequence control. Therefore, the efficiency of the new system is considerably increased to about 70%, its weight and size is decreased much. Its power factor is a great deal increased to about 0.95. Experiment results have demonstrated that the highly efficient EDM pulse power supply is capable of low electrode wear, high speed, stable machining.

• Periodical: Key Engineering Materials (Volumes 291-292)
• Pages: 567-572
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.291-292.567
• Online since: August 2005
• Authors: Yu Kui Wang, Bo Yan Song, Wan Sheng Zhao
• Keywords: EDM Pulse Power Supply, High-Efficiency, Power Factor Correction (PFC), Pulse Width Modulation (PWM)

References

[1] Liu Jinchun, Zhao Jiaqi and Zhao Wansheng: Nontraditional Machining (China Machine Press, Beijing 2003).

[2] Zhao Wansheng: Advanced Electrical Discharge Machining Technology (National Defense Industry Press of China, Beijing 2003).

[3] Wu Wenjiang, Mu Xinhua, Liu Chuang, Yang Zhiyong: Research on Electrical Discharge Machining Pulse Power Based on Current Control Measure, PowerElectronics, Vol. 36 (2002), No. 4, pp.6-9.

[4] Haruki OBALA, Tsuyoshi OHSUMI, Masatoshi HATANO: Development of Twin-type Resistorless Power Supply for Electrical Discharge Machining. Proc. of International Symposium for Electro Machining XIII, Bilbao, 2001: 153-160.

DOI: 10.2526/jseme.36.82_33

[5] Rosario Casanueva, Luis A. Chiquito, Francisco J. Azcondo, Salvador Bracho: Current Source LCC Resonant Converter for an EDM Power Supply, Proc. of the 27th Annual Conference of the IEEE Industrial Electronics Society, 2001: 1027-1032.

DOI: 10.1109/iecon.2001.975916

[6] Rosario Casanueva, Francisco J. Azcondo, Salvador Bracho: Series-parallel resonant converter for an EDM power supply. Proc. of International Symposium for Electro Machining XIV, 2004: 153-160.

DOI: 10.1016/j.jmatprotec.2003.10.038
