Electromagnetic Field Analysis and Measurement for High Speed Attraction Type Magnetic Levitation Vehicle Systems

Abstract:

Research achievements in a high speed attraction type magnetic levitation vehicle experimental system are reported. The high speed attraction type magnetic levitation vehicle constitutes a typical long stator linear synchronous motor. The study on levitation and propulsive electromagnetic fields is of great importance and is studied. Owing to the influence of the stator grooves and the material discontinuousness, the magnetic field distribution is very complex to be analyzed in analytical forms. The magnetic fields in the air gap are determined using the finite element method. The levitation force and thrust produced by the levitation magnetic field and the propulsive magnetic field are calculated. They are found to vary following the change of the air gap and exciting current. A magnetic field strength measurement system based on a hall sensor is designed. Experimental results are compared with the results from the magnetic field analysis.

• Periodical: Key Engineering Materials (Volumes 295-296)
• Pages: 655-660
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.295-296.655
• Online since: October 2005
• Authors: D.X. Chen, M.C. Pan, F.L. Luo, Z.W. Kang, W.G. Tian, Yun Yu Hu
• Keywords: Electromagnet, Hall Sensor, Linear Synchronous Motor, Magnetic Field Analysis, Magnetic Field Measurement, Magnetic Levitation Vehicle, Semiconductor Materials

References

[1] J. Meins and L. Miller: IEEE Trans on Magnetics, Vol. 24 (1988), p.808.

[2] P.K. Sinha: IEE Control Engineering Series 30 (Peter Peregrinus Ltd, 1987).

[3] P.P. Silvester and R.L. Ferrari: Finite Elements for Electrical Engineers (Cambridge University Press, Cambridge 1991).

[4] L.N. Jiao, Z.Y. Fu and F. Chen: Journal of Jiaozuo Institute of Technology, Vol. 19 (2000), p.434.

[5] S.Y. Yang, G.Z. Ni, S.L. Ho, J.M. Machado, M.A. Rahman and H.C. Wong: IEEE Trans on Magnetics, Vol. 36 (2000), p.644.

[6] S. Bobbio, F. Delfino, P. Girdinio and P. Molfino: IEEE Tran on Magnetics, Vol. 36 (2000), p.663.

[7] F. Luo and K.L. Zhang: Electric Drive for Locomotives, Vol. 19 (2002), p.32.

[8] Q.L. Li, X.K. Wang, D. Wu, C.Y. Liu and Z.D. Shi: Journal of Tsinghua University, Vol. 40 (2000), p.20.
