Development of an On-Line Bowl-Shaped Diamond Grinding Wheel Dresser

Abstract:

In this paper, a new on-line diamond grinding wheel dresser, which is comprised of high-speed rotatory dressing wheel, micro-feed mechanism and control system, is presented. The principle of micro-feed machine working at requiring dressing depth, the control method of the dressing wheel speed adjusting and dressing depth, and structure of the control system are also introduced. The experiments we have done show that the dresser reach the goal of diamond grinding wheel on-line dressing.
