Process Integration of Fatigue Analysis for Welded Bogie Frames

Abstract:

The automation of fatigue durability analysis for welded bogie frames according to the UIC-code is proposed by using the ModelCenter, which enables several tools used in fatigue durability analysis to be integrated, i.e. I-DEAS, ANSYS and BFAP, and an iterative analysis of geometrical changes in transom support bracket to be performed. In additions wrapping programs to control I/O-data and interfaces of these tools were developed. The developed automation technique brings not only a significant decrease in man-hour required for durability analysis, but also provides a platform for multidisciplinary engineering activities.

• Periodical: Key Engineering Materials (Volumes 321-323)
• Pages: 624-627
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.321-323.624
• Online since: October 2006
• Authors: Seung Ho Han, Je Sung Bang, Chae Whan Rim, Kwang Soon Lee, Kwang Ki Lee, See Yeob Song
• Keywords: Fatigue Durability Analysis, Multidisciplinary Engineering, Process Integration, Welded Bogie Frame, Wrapping Program

References

[1] ModelCenter Ver. 6. 1, Phoenix Integration, Inc.

[2] UIC Code 615-4, International Union of Railways (1994).

[3] S. Machida et al. : J. of SNAJ Vol. 171 (1992), pp.477-484.

[4] S. Han et al. : Steel Research Vol. 71 No. 11 (2000), pp.466-473.

[5] DV952, Deutsche Bundesbahn (1977).

[6] BS7608, British Standard (1993).

[7] Report for Development of High Speed Train, KOROS, 98-2-1-5 (1999).
