Paper Title:
Active Vibration Control of the Print Circuit Boards Using Piezoelectric Bimorphs
  Abstract

Piezoelectric bimorphs were assessed for their capabilities to be used as control actuators for vibration suppression of the print circuit boards (PCBs). Plate structures made of FR-4, a widely used industrial-grade material for manufacture of PCBs, were considered. An advanced and structured control algorithm, linear quadratic regulator with output feedback (LQROF), was used for active vibration control of the PCB structures. Experimental results showed that the LQROF control is a more robust algorithm than the classic control using the direct velocity feedback, and piezoelectric bimorph actuators present a great potential for active vibration control of the PCBs, and smart composites with embedded actuators.

  Info
Periodical
Key Engineering Materials (Volumes 334-335)
Edited by
J.K. Kim, D.Z. Wo, L.M. Zhou, H.T. Huang, K.T. Lau and M. Wang
Pages
1081-1084
DOI
10.4028/www.scientific.net/KEM.334-335.1081
Citation
H.C. Yeo, N. Guo, H. Du, M. Chen, "Active Vibration Control of the Print Circuit Boards Using Piezoelectric Bimorphs", Key Engineering Materials, Vols. 334-335, pp. 1081-1084, 2007
Online since
March 2007
Export
Price
$35.00
Share
