Spinning- Inflated-Ballonet Polishing Tool and its Application in Curved Surface Polishing

Abstract:

In this paper, a novel spinning-inflated-ballonet polishing tool for curved surface of mould is proposed. The head of the tool is a spherical spinning-inflated-ballonet whose inner air pressure can be controlled on-line and the head surface is covered with a suitable polishing cloth. The head can be rotated in high speed driven by an electromotor or high pressure airflow and its rotating speed can be adjusted. The flexibility of the head, the polishing force in radial direction and the contact area between the head surface and the curved surface of the work-piece can be controlled by adjusting the feeding deepness and ballonet pressure of the tool. The structure and the polishing mechanism of the novel polishing tool are introduced. The application of robot polishing system based on the novel polishing tool also is discussed. Finally the polishing control strategy of curved surface is researched.

• Periodical: Key Engineering Materials (Volume 339)
• Pages: 21-25
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.339.21
• Online since: May 2007
• Authors: Shi Ming Ji, Li Zhang, Xian Zhang, Yue Hua Wan, Hai Ping He, Ju Long Yuan, Qiao Ling Yuan, Ming Sheng Jin
• Keywords: Flexible Polishing Tool, Free-Form Surface Polishing, Surface Form, Surface Texture

References

[1] D.D. Walker, A.T. Beaucamp, R.G. Bingham and et al: Proc. SPIE, Vol. 4842 (2002), pp.73-84.

[2] D.D. Walker and et al: Proc. Large Lenses and Mirrors Conference, UCL, pub. SPIE (2001), pp.106-111.

[3] D.D. Walker and et al: Proc. SPIE, Vol. 4451 (2001), pp.267-276.

[4] D.D. Walker and et al: Optics Express, Vol. 11 (2003), pp.958-964.

[5] S-W Kim, D. Rees, D. Walker and et al: Proc. SPIE, Vol. 2775 (1996), pp.491-496.

[6] L. Guvencand and K. Srinivasan: Mechanical systems and signal processing, Vol. 9 (1995), pp.31-38.

[7] D.G. Xie, B. Gao, Y.X. Yao and Z.J. Yuan: Key Engineering Materials, Vol. 304-305 (2006), pp.335-339.
