Two-Parameter Criteria for Ductile Crack Initiation and Propagation in High-Grade Line Pipes

Abstract:

Full-scale burst test data of high-grade line pipes for high-pressure gas pipelines were referred to, and 3-D elastic-plastic finite element analysis was carried out using the test data for the calculation of fracture parameters. Ductile crack initiation was evaluated by the intersection of a toughness locus and a crack driving force curve, where the toughness locus was indicated by the relationship between the critical equivalent plastic strain and the stress triaxiality, and the crack driving force curve was shown by a history of the equivalent plastic strain and the stress triaxiality at characteristic distance. In addition, ductile crack rapid propagation was assessed by the relationship between the critical CTOA and the global constraint factor, where the critical CTOA remained almost constant because of high constraint.

• Periodical: Key Engineering Materials (Volumes 348-349)
• Pages: 493-496
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.348-349.493
• Online since: September 2007
• Authors: Yoichi Kayamori, P.S.J. Crofton, Roderick A. Smith
• Keywords: CTOA, Ductile Fracture, Equivalent Plastic Strain, Global Constraint Factor, Line Pipe, Stress Triaxiality

References

[1] J.F. Kiefner, W.A. Maxey, R.J. Eiber and A.R. Duffy: ASTM STP 536, (1973), p.461.

[2] W. A. Maxey: Proc. 5th Symposium on Line Pipe Research, Houston, Texas, Nov. (1974), p. J1.

[3] Y. Kayamori, S. Hillmansen, P. S. J. Crofton and R. A. Smith: submitted to Int. J. Pres. Ves. & Piping, (2007).

[4] Y. Kayamori, S. Hillmansen, P. S. J. Crofton and R. A. Smith: Materials Science Forum, Vol. 539-543, (2007), p.2180.

DOI: 10.4028/www.scientific.net/msf.539-543.2180

[5] Y. Kayamori, S. Hillmansen, P. S. J. Crofton and R. A. Smith: submitted to Key Engineering Materials, (2007).

[6] J.C. Newman Jr., C.A. Bigelow and K.N. Shivakumar: Eng. Frac. Mech. Vol. 46 Issue 1 (1993), p.1.

[7] S. Kawaguchi, N. Hagiwara, T. Masuda and M. Toyoda: Proc. Int. Conf. Application and Evaluation of High-grade Linepipes in Hostile Environment, Yokohama, Japan, (2002), p.881.

[8] S. Kawaguchi: Study on the evaluation of ductile crack initiation criterion for high-pressure gas pipelines made by high-grade line pipes, Ph. D Thesis, Osaka University, March, (2004). (in Japanese).

[9] S. Kawaguchi, N. Hagiwara, T. Masuda, T. Inoue, C. Christensen, H.P. Nielsen and P.B. Ludwigsen: Proc. Int. Conf. Application and Evaluation of High-grade Linepipes in Hostile Environment, Yokohama, Japan, (2002), p.557.

[10] G. Demofonti, G. Guzzichelli, S. Venzi and M. Kanninen: Pipeline technology, edited by R. Denys, Vol. II, Elsevier Science, (1995), p.503.

[11] D.L. Rudland, G.M. Wilkowski, Z. Feng, Y.Y. Wang, D. Horsley and A. Glover: Eng. Frac. Mech. Vol. 70 Issues 3-4 (2003).
