The Research of Data Acquisition and Control Method about On-Line Measurement System on High Precision of Large Diameter

Abstract:

The system bases on the theory of rolling-wheel to measure large diameter, by applying double counters to record the round grating’s signal and using the method of three rolling-wheels paralleling data acquisition, redundancy measurement and error amendment and so on, realizes the measurement of large axis workpieces’ diameter with high precision in on-line and dynamic condition. The experiment shows that the system can achieve the on-line dynamic measurement precision in m D µ 5 at the range of the diameter m m D 5 ~ 1 = complexly combining hardware and soft under the relevant control methods.

• Periodical: Key Engineering Materials (Volumes 381-382)
• Pages: 129-132
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.381-382.129
• Online since: June 2008
• Authors: Biao Wang, Xiao Fen Yu, H. Zeng
• Keywords: Data Acquisition (DAQ), Data Control, Error Amendment, Online Measurement, Rolling Wheel, Round Grating

References

[1] Jiankun Wu, Guozhong Liu and Wenyi Deng: Journal of Beijing Institute of Machinery, Vol. 14 (1999), No. 2, pp.25-29.

[2] G.Y. Zhang, X.P. Xu, X.H. Fu, L. Yang and C. Z. Li: Journal of Materials Processing Technology, Vol. 129(2002), pp.653-657.

[3] Bin Li and Jing-wen Liang: Precision Engineering, Vol. 21 (1997), No. 1, pp.36-42.

[4] Yanxin Xu, Xiaofen Yu: Journal of China Institute of Metrology, Vol. 14 (2003), No. 3, pp.189-192.

[5] Zhen Li, Jianli Wang, Haining Liu and Liyuan Wang: Tool Engineering, Vol. 32 (1998), No. 6, pp.37-39.
