Online Measurement for Dimensions of Thermal Train Wheel

Abstract:

This paper presents a method for online measurement of the dimensions of thermal train wheel by one frame of photo-thermal image. A measurement system and its mathematics model is setup. The effect of the spectrum of laser source to restrain thermal background noise is analyzed, then, a special laser is selected. A weighting method of the gray value transform is added into the image process. The high temperature fields of a measured train-wheel are analyzed by use of limited element method. The experiment result shows that the measurement standard deviation of the thermal train-wheel rim is less than 0.55 mm.

• Periodical: Key Engineering Materials (Volumes 381-382)
• Pages: 133-136
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.381-382.133
• Online since: June 2008
• Authors: Y. Yang, S. Deng, Z. Hong
• Keywords: Dimension, Image Process, Measurement, Photothermal, Train-Wheel

References

[1] Yang Yongyue and Deng Shanxi: Solar Academic Journal, Vol. 24(2003), No. 2, pp.232-235.

[2] Yang Yongyue and Deng Shanxi: 3rd International Symposium on Instrumentation Science and Technology, China, Vol. 1(2004), pp.1089-1094.

[3] Yang Yongyue, Deng Shanxi: 3rd International Symposium on Precision Mechanical Measurements, China, Vol. 6280(2006), 62803p. 1-6.

[4] Cheng Chun, Technique and Arithmetic for Computer Image Manipulation (Tsinghua University Press, Bejing 2003).

[5] Zhang Jiarong and Zhao Tingyuan: Handbook of Calorific Physics Character for Common Material (New Times Press, Bejing 1987).

[6] Yang Yongyue and Deng Shanxi: Transactions of the Chinese Society for Agricultural Machinery, Vol. 36(2005), No. 9, pp.131-135.
