Fundamental Experiment of Laminated Templates Electro-Deposition in Manufacturing Metal Part

Abstract:

Laminated templates electro-deposition is an original manufacturing technology that is aimed at micro-scale metallic structures fabrication. Based on the discrete piling-up principal and electrodepositing method, it realizes a manufacturing simplification from the traditional machining to the repetition of template-assisted planar deposition in forming a three-dimensional complicated object. The ability to control the deposit surface nouniformity is a key to successful implementation for each planar depositing. Profile geometry and current configuration are alternated in experiment and thought as the major factors influencing deposit surface roughening. The results show that the surface of the deposits obtained by pulse electroforming has better performance in deposit thickness distribution and properties of the deposits. Optimized parameters have been obtained from the preliminary experiments in which 0.3millimeters-thick epoxy templates and 4~6A/dm2 current density were used at 40+ and a bulk of copper parts, section size 30mm×30mm and 7mm thick were produced and tested for their mechanical performance.

• Periodical: Key Engineering Materials (Volumes 392-394)
• Pages: 189-194
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.392-394.189
• Online since: October 2008
• Authors: Hui Fan, Zong Jun Tian, Y.H. Huang, Z.D. Liu, X.C. Wang
• Keywords: Advanced Fabrication, Electro-Deposition, Multi-Laminated, Template

References

[1] G.N. Li, C.J. Huang, L. LUO, M. GUO, Z.Y. YU and J. Yu: Microfabrication Technology, (2006) No. 6, p.1 (In Chinese).

[2] M.X. Hu and N. Wang: Vol. 25 (2006) No. 11, p.38 (In Chinese).

[3] X. D Kong, Y.L. Zhang, H.Y. Song and W.J. LU: Micronanoelectronic Technology, (2004) No. 11, p.32 (In Chinese).

[4] L.C. Li, J. B Yang, R. Vaia and L.M. Dai: Synthetic Metals, Vol. 154 (2005) No. 1-3, p.225.

[5] Y. Konishi, M. Motoyama, H. Matsushima, Y. Fukunaka, R. Ishii and Y. Ito: Journal of Electroanalytical Chemistry, Vol. 559 (2003), No. 15, p.149.

DOI: 10.1016/s0022-0728(03)00157-8

[6] N.I. Kovtyukhova, B.R. Martin, J.K.N. Mbindyo, T.E. Mallouk., M. Cabassi and T.S. Mayer: Materials Science and Engineering C, Vol. 19 (2002), p.255.

DOI: 10.1016/s0928-4931(01)00395-2

[7] Y.P. Zhao, Y.H. Huang, J.F. Zhao, Z.D. Liu and Z.J. Tian: Journal of Nanjing University of Aeronautics & Astronautics, (2004) No. 4, p.458 (In Chinese).

[8] J.M. Yang, D. H Kim, D. Zhu and K. Wang: International Journal of Machine Tools and Manufacture, Vol. 48 (2008), p.329.

[9] H.H. Yang and S.W. Kang: International Journal of Machine Tools and Manufacture, Vol. 40 (2000) No. 7, p.1065.

[10] H.J. Liu, L.Q. Du, J. Qin and S.M. Zhu: Chinese Journal of Sensors and Actuators, Vol. 19 (2006) No. 5, p.1481 (In Chinese).

[11] Z.W. Zhu, D. Zhu, N.S. Qu and W.N. Lei: The Chinese Journal of Nonferrous Metal, Vol. 15 (2005) No. 43, p.251.

[12] K.H. Hou, M.C. Jeng and M.D. Ger: Wear , Vol. 262 (2007), p.833.

[13] M.S. Chandrasekar and M. Pushpavanam : Electrochimica Acta, Vol. 53 (2008), p.3313.

[14] D. Zhu, N.S. Qu and K.C. Chan: Journal of Material Processing Technology, Vol. 63 (1997) No. 11, p.844.
