Damage Analysis of Waterproof Layer in Composite Tunnel Lining Based on Theory of Plate with Large Deflection

Abstract:

: In order to analyze the cause of water leakage in highway tunnels, the damage property of waterproof board in composite tunnel lining with concrete matrix defects under hydraulic pressure was studied using Galerkin method for plates with large deflection. The deflection, stress and strain of waterproof boards were calculated in the conditions of rectangular and elliptic boundary due to concrete matrix defects. First strength theory was used to determine the critical load of the board and the critical depth of the defect. Investigation results showed that the maximum principal stress generates in the middle of longer side in the rectangular boundary condition and in the center in the elliptic boundary condition, the failure of the waterproof board under certain hydraulic pressure is related with the dimensions of concrete matrix defects and the dimension of the concrete matrix defect needs to be controlled in the design and construction of waterproof layer for tunnels.

• Periodical: Key Engineering Materials (Volumes 400-402)
• Pages: 245-250
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.400-402.245
• Online since: October 2008
• Authors: Xian Yu Jin, Nan Guo Jin, Xiang Lin Gu
• Keywords: Concrete Matrix, Critical Load, Galerkin's Method, Waterproof Layer

References

[1] N. Hiroshi, K. Toshikazu, F. Mamoru, et al.: Unified construction of running track tunnel and crossover tunnel for subway by rectangular shape double track cross-section shield machine. Tunnelling and Underground Space Technology, Vol. 18, No. 2(2003).

DOI: 10.1016/s0886-7798(03)00034-8

[2] R. P. Benson: Design of unlined and lined pressure tunnels. Tunnelling and Underground Space Technology, Vol. 4 No. 2(1988), pp.155-170.

DOI: 10.1016/0886-7798(89)90049-7

[3] K. Kalman: History of the sprayed concrete lining method-part II: milestones up to the 1960s. Tunnelling and Underground Space Technology, Vo; 18, No. 1(2003), pp.71-83.

DOI: 10.1016/s0886-7798(03)00006-3

[4] R. Commolli, F. Cuaz, V. Ferro, et al.: The channel expressway: twin-bored road tunnels under the English Channel. Tunnelling and Underground Space Technology, Vol. 1, No. 3-4(1986), pp.261-269.

DOI: 10.1016/0886-7798(86)90007-6

[5] AFTES Working Group No. 14: Recommendations for the treatment of water inflows and outflows in operated underground structures. Tunnelling and Underground Space Technology, Vol. 4, No. 3(1989), pp.343-407.

DOI: 10.1016/0886-7798(89)90084-9

[6] Y. Q. Yang: Theory of plates, China railway Publisher, Beijing(1980), (In Chinese).

[7] H. Z. Shan: Material mechanics (I), Higher Education Publisher, Beijing(1999), (In Chinese).
