A Study on a Tool to Support Configuration Design of 5-Axis Machine Tools

Abstract:

Design process of a machine tool is sometimes experience basis and time-consuming. The author has proposed a design tool for machine tools based on form-shaping theory and robust design technique. The tool can determine suitable configuration of machine tools, or important design parameters and error factors that affect machine tool performance, without prototyping. Especially in case of recently popular 5-axis machine tools, since the number of motion axis increases, there are huge options of axes combinations. It is difficult for machine tool designers to simulate the performance of every design option. Contrarily, the proposed design tool can clarify which design option of machine tool have better performance. In this paper, the tool is applied to the design of 5-axis machine tools. It enables to narrow the selection and make the design procedure more efficient. It also tries to suggest where the rotational motion axes should be placed. Finally, it is concluded that the design tool is effective in supporting configuration design of 5-axis machine tools structure where design knowledge has not been completely established.

• Periodical: Key Engineering Materials (Volumes 407-408)
• Pages: 185-188
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.407-408.185
• Online since: February 2009
• Authors: N. Mishima
• Keywords: 5-Axis Machine Tool, Concept Design, Form-Shaping Theory, Machine Configuration, Robust Design

References

[1] N. Mishima, Design evaluation method for miniature machine tools utilizing form-shaping theory, Proc. of ASME/DETC '02, Chicago, IL, USA, Sept. 2003, CR-ROM (DETC/DAC-48787).

DOI: 10.1115/detc2003/dac-48787

[2] N. Mishima, Derivation of design guidelines for miniature machine tools, Proc. of ASME/DETC '04, DETC/DAC-57091, Salt Lake City, UT, Sept. (2004).

[3] G. Taguchi and S. Konishi, Quality Engineering Series Vol. 1-4, ASI Press, (1994).

[4] D. N. Reshtov and V. T. Portman, Accuracy of Machine Tools, ASME Press, New York, (1988).

[5] R. P. Paul, Robot Manipulators, THE MIT press, Cambridge (1981).

[6] M. Sato, Design and Performance of 5 -Axis Machines in Japan, Proc. of The 12th International Machine Tool Engineer's Conference, Nov. 2006, 167-189.
