Study of Virtual Numerical Control Milling Simulation System

Abstract:

Virtual numerical control milling simulation system, based on UG, is studied oriented to low utilization of NC machines. A virtual machine tools library, standard fixture library and visual machine tool processing environment were established by the second development techniques of UG and VC++. Through the example of XH715 NC machine center, tool path and motion of miller were simulated separately; at last processing scheme was evaluated and optimized. The experimental results show this system possesses good utility, and the utilization of machine tools could thus be improved.
