Mathematical Transformation of Machine Settings from Cradle-Type to Cartesian-Type Hypoid Generator

Abstract:

A mathematical model for translating machine settings from universal Cradle-Type hypoid generator to Cartesian-Type hypoid generator is proposed in this paper. A mathematical model of universal Cradle-Type hypoid generator was proposed by Fong [12] to simulate conventional hypoid generators including face milling and face hobbing machines. A few years ago, the Gleason Works presented the Phoenix hypoid generator, which is a Cartesian-Type machine, and the machine is gaining good commercial success. Therefore, we proposed a mathematical transformation model to translate the machine settings from conventional Cradle-Type hypoid generator to the new Cartesian-Type CNC machine. The proposed mathematical equations can be used to implement the existing cutting method on the six-axis CNC machine

• Periodical: Key Engineering Materials (Volumes 419-420)
• Pages: 365-368
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.419-420.365
• Online since: October 2009
• Authors: Pei Yu Wang, Zhang Hua Fong
• Keywords: Cartesian Type CNC, Cradle Type, Hypoid Gear

References

[1] Litvin, F.L., and Gutman, Y.: Methods of Synthesis and Analysis for Hypoid Gear-Drives of Formate and Helixform. ASME Journal of Mechanical Design, Vol. 103(1981), No. 1, pp.83-113.

DOI: 10.1115/1.3254890

[2] Litvin, F.L., and Zhang Y., Local Synthesis and Tooth Contact Analysis of Face-Milled Spiral Bevel Gears, NASA Technical Report 90-C-028, Washington DC. (1991(b).

[3] Litvin, F.L., Zhang Y., and Lundy M.: Determination of Settings of a Tilted Head Cutter for Generation of Hypoid and Spiral Bevel Gears. ASME PTG. (1989b).

DOI: 10.1115/1.3258950

[4] Litvin, F.L., Gear Geometry and Applied Theory, Prentice Hall, Englewood Cliffs, NJ 07632 (1994).

[5] Argyris, J., Fuentes, A., and Litvin, F.L.: Computerized integrated approach for design and stress analysis of spiral bevel gears. Comput. Methods Appl. Mech. Engrg., Vol. 191(2002), pp.1057-1095.

DOI: 10.1016/s0045-7825(01)00316-4

[6] Pei-Yu Wang, and Zhang-Hua Fong: Adjustability Improvement of Face-Milling Spiral Bevel Gears by Modified Radial Motion (MRM) Method. Mechanism and Machine Theory 40 (2005) , pp.69-89.

DOI: 10.1016/j.mechmachtheory.2004.05.011

[7] Gosselin, C.J. and Cloutier, L.: The Generating Space for Parabolic Motion Error of Spiral Bevel Gears Cut by the Gleason Method. ASME Journal of Mechanical Design, Vol. 115(1993), No. 3, pp.483-489.

DOI: 10.1115/1.2919215

[8] Gosselin, C., Shiono, Y., Nonaka, T., and Kubo, A.: A Computer Based Approach Aimed at Reproducing Master Spiral Bevel and Hypoid Pinions and Gears. AGMA paper 96FTM1. (1996).

[9] Gosselin, C., Nonaka, T., Shiono, Y., Kubo A., and Tatsuno, T.: Identification of the Machine Settings of Real Hypoid Gear Tooth Surfaces. ASME, Journal of Mechanical Design, Vol. 120(1998), pp.429-440.

DOI: 10.1115/1.2829170

[10] Lin, C.Y., Tsay, C.B., and Fong, Z.H.: Computer-Aided Manufacturing of Spiral Bevel and Hypoid Gears with Minimum Surface Deviation. Mechanism and Machine Theory, Vol. 33(1998), No. 6, pp.785-803.

DOI: 10.1016/s0094-114x(97)00101-8

[11] Goldrich, R. N., Theory of 6-axis CNC generation of spiral bevel gear and hypoid gears, AGMA paper 89FTM9. (1989).

[12] Fong, Z.H.: Mathematical Model of Universal Hypoid Generator with Supplemental Kinematic Flank Correction Motions. Transactions of the ASME, Vol. 122(2000), pp.136-141.

DOI: 10.1115/1.533552

[13] Stadtfeld, H. J., Advanced Bevel Gear Technology, (The Gleason works, 2000).
