Data Management System for Complex Mechanical Product in Collaborative Simulation Environment

Abstract:

In order to implement collaborative work in enterprises, it is important to exchange and share data during product design process. According to the characteristics and types of simulation data for mechanical properties analysis, an effective data management method is presented. Based on the functional framework of collaborative simulation environment, a new database system has been designed by combining relational database and content repository. The content repository for simulation data has been established and designed by user-defined node type whose model is a simple hierarchy. In this repository, simulation metadata have been stored as node properties. Furthermore, simulation data files can be stored in node which facilitates the upload and download of files. In the mean while, simulation flow data can be stored in relational database. An engineering application is employed to demonstrate the feasibility and practicability of the data management system.

• Periodical: Key Engineering Materials (Volumes 431-432)
• Pages: 196-200
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.431-432.196
• Online since: March 2010
• Authors: Zhao Xia He, Geng Liu, Lan Liu, Bing Han
• Keywords: Collaborative Simulation Environment, Content Repository, Data Management System, Simulation Data

References

[1] A.A. Joshi: Computers and Information in Engineering Conference(Salt Lake City, USA, September 28 - October 03 Oct, 2004 ).

[2] Information on http: /articles. e-works. net. cn/cae/article50173. htm. (in Chinese).

[3] H. Kin, B. Malone: 45th AIAA/ASME/ASCE/AHS/ASC Structures, Structural Dynamics & Materials Confer(California, USA, April 19 - 22, 2004).

DOI: 10.2514/msdm04

[4] Y.P. Wang and J.T. Deng: Computer Integrated Manufacturing Systems, Vol. 12 (5) (2007), p.905. (in Chinese).

[5] R.J. Hong, Q.H. Sun and Y. Fu: Journal of Southeast University (Natural Science Edition), Vol. 36 (5) (2006), p.711. (In Chinese).

[6] David Nuescheler and Day Software, Inc: JSR 170: Content Repository for Java TM technology API (Java Community Process Release 2005).

[7] Information on http: /www. ibm. com/developerworks/java/library/j-jcr/?S_TACT=105AGX52&S_CMP=cn-a-j.

[8] Paul DuBois and MySQL: The Definitive Guide to Using, Programming, and Administering MySQL 4. 1 and 5. 0, 3d ed (China machine press, China 2004) (In Chinese).

[9] Information on http: /jcp. org/aboutJava/communityprocess/review/jsr170/index. html.

[10] Y. Y Ji and C.Q. Nie: Computer and Modernization, 11(2007), p.81.
