Study on the Fabrication and Cutting Performance of HFCVD Diamond Coated Silicon Nitride Inserts

Abstract:

Microcrystalline diamond (MCD) and fine-grained diamond (FGD) films are deposited on silicon nitride (Si3N4) inserts using the hot filament chemical vapor deposition (HFCVD) method. Scanning electron microscope (SEM), X –ray diffraction (XRD) and Raman spectrum are employed to characterize these as-deposited diamond films. Cutting performance of as-fabricated CVD diamond coated Si3N4 inserts is examined in dry turning glass fiber reinforced plastics (GFRP) material, comparing with the uncoated Si3N4 inserts. The results indicate that the tool failure is mainly attributed to its severe flank wear, which is caused by continuous friction and impact brought by many hard SiO2 particles distributed in the GFPR work piece. The lifetime of Si3N4 inserts can be prolonged by depositing MCD or FGD films on them and the FGD coated insert shows better wear resistance than the MCD coated one.

You might also be interested in these eBooks

Machining and Advanced Manufacturing Technology X

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 431-432)

Pages:

515-518

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.431-432.515

Citation:

Cite this paper

Online since:

March 2010

Authors:

Guo Dong Yang, Bin Shen, Fang Hong Sun, Zhi Ming Zhang, Ming Chen

Keywords:

Cutting Performance, Hot Filament Chemical Vapor Deposition (HFCVD), Silicon Nitride Insert

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] B. Shen and F.H. Sun: Diamond and Related Materials Vol. 18(2-3) (2009), p.238.

Google Scholar

[2] B. Shen, F.H. Sun, H.G. Xue, M. Chen and Z.M. Zhang: Surf. Eng. Vol. 25 (2009), p.70.

Google Scholar

[3] F.A. Almeida, M. Amaral, F.J. Oliveira and R.F. Silva: Diamond and Related Materials, Vol. 15 (11-12) (2006), pp. (2029).

Google Scholar

[4] R.P. Martinho, F.J.G. Silva and A.P.M. Baptista: Wear, Vol. 263 (7-12) (2007), p.1417.

Google Scholar

[5] R.P. Martinho, F.J.G. Silva and A.P.M. Baptista: Vacuum 82. (12) (2008), p.1415.

Google Scholar

[6] G. Castro, F.A. Almeida, F.J. Oliveira, A.J.S. Fernandes, J. Sacramento and R.F. Silva: Vacuum 82. (12) (2008), p.1407.

Google Scholar

[7] T. Wang, H.W. Xin, Z. M. Zhang, Y. B. Dai and H. S. Shen: Diam Relat Mater. 13 (2004) 6.

Google Scholar

[8] M.I. De Barros and et al.: Diamond Relat. Mater. 11 (2002) 1544.

Google Scholar
