Wave Front Correction and Measurement by Using a Liquid Crystal Spatial Light Modulator

Abstract:

To correct wave front distortion, a phased only Liquid Crystal Spatial Light Modulator (LCSLM) is used. LCSLM can modulate the phase of the incident beam by changing the electric field applied to the transparent electrodes of a liquid crystal cell. The voltage change causes the refractive index of the liquid crystal change, so a phase shift produces. The distortion of a wave front can be measured by using a wave front interferometer. Since each pixel of SLM may be addressed and controlled independently, so proper voltage is supplied to each pixel to compensate the phase corresponding to the distortion. Before wave front correction, the LCSLM is tested and corrected by employing a Twyman-Green interferometer, which shows the relationship between the applied voltage and the phase value of each pixel. Experiment result shows that after error compensation of LCSLM, the wave front distortion correction accuracy reaches 0.06 λ.

• Periodical: Key Engineering Materials (Volume 437)
• Pages: 319-323
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.437.319
• Online since: May 2010
• Authors: Jian Zhang, Li Ying Wu, Li Min Zou
• Keywords: Liquid Crystal, Spatial Light Modulator, Wave Front Correction

References

[1] P.F. McManamon, T.A. Dorschner, D.L. Corkum et al: Optical phased array technology. Proc. IEEE. 84(2) (1996), pp.268-298.

DOI: 10.1109/5.482231

[2] Gordon D. Love: Wave-front Correction and Production of Zernike Modes with a Liquid-Crystal Spatial Light Modulator. Applied Optics. 36 (1997), pp.1517-1524.

DOI: 10.1364/ao.36.001517

[3] S. Harris: Characterization and Application of a Liquid Crystal Beam Steering Device. Proc. SPIE. Vol. 4291 (2001), pp.109-119.

[4] Steve Serati and Jay Stockley: Advances in Liquid Crystal Based Devices for Wavefront Control and Beam Steering. Proc. SPIE. Vol. 5894 (2005), pp. 58940K-1-13.
