Full-Field Laser Vibrometer for Instantaneous Vibration Measurement and Non-Destructive Inspection

Abstract:

We describe a system for real-time, full-field vibrometry, incorporating features of high-speed electronic speckle pattern interferometry (ESPI) and laser Doppler velocimetry (LDV). Based on a 2D interferometric sensor array, comprising 16×16 parallel illumination and detection channels, the matrix laser vibrometer (MLV), captures full-field data instantaneously, without beam scanning. The instrument design draws on the advantages of scale offered by modern telecommunications fiber optic and digital electronics. The resulting architecture, comprising a compact measurement probe linked by fiber optic umbilical to a remote electronics unit, facilitates practical application to the full-field study of transient vibrations and rapid non-destructive inspection of composite materials.

• Periodical: Key Engineering Materials (Volume 437)
• Pages: 407-411
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.437.407
• Online since: May 2010
• Authors: James M. Kilpatrick, Vladimir B. Markov
• Keywords: Laser Doppler Velocimetry, Nondestructive Testing (NDT), Vibration Studies

References

[1] F. Chen, W.D. Luo, M. Dale, et al: Optics and Lasers in Eng. Vol. 40 (2003), p.459.

[2] J.M. Kilpatrick, A.J. Moore, J.S. Barton, et al: Optical Letters. Vol. 25 (2000) p.1068.

[3] T. Wu, J.D.C. Jones, A.J. Moore: Appl. Optics. Vol. 45 (2006), p.5845.

[4] H. Helmers, M. Schellenberg: Opt. and Laser Techn. Vol. 35 (2003) p.587.

[5] E. Cupido, S. Morel, D. Smith: Proc. of IMAC XXI. Orlando, USA (2003).

[6] V. Aranchuk et al: Proc. SPIE. Vol. 5794 (2005) pp.624-631.

[7] T. Hachiga, N. Furuichi, J. Mamitsu, K. Hishida: Experiments in Fluids. Vol. 24 (1998), p.70.

[8] S.W. Doebling, C.R. Farrar, et al: Technical Report LA-13070-MS. Los Alamos National Laboratory (1996).

[9] A.Z. Khan, A.B. Stanbridge and D.J. Ewins: Opt. Laser Eng. 32 (2000), pp.583-592.

[10] P. Castellini, D.P. Willemann, G.M. Revel: Proc. of IMAC XXIII. Orlando, USA (2005).

[11] P. Cawley, et al: Journal of Strain Analysis. Vol. 14 (1979), p.49.

[12] D. Donskoy, A. Sutin and A. Ekimov: )DT&E International (2000), p.1.

[13] J. Tomblin, L. Salah and Y. Ng.: OAR Final Report. DOT/FAA/AR-01/40. (2001).
