Non-Contact Geometry Inspection of Workpieces with Optically Non-Cooperative Surfaces

Abstract:

In order to produce optically cooperative surfaces to use triangulation measuring systems, the methods of surface and thin-coating technology are resorted to. Among these number physical methods such as PVD technology, (electro-)chemical treatment as, for example, electrochemical etching and electroless coatings as well as mechanical treatments of the components by means of glass-bead and corundum blasting. The processes mentioned are suitable for producing optically cooperative surfaces since, owing to the corresponding test parameters, a change of the component's surface occurs at the sub-micrometer scale. Currently, no indication in the literature is provided that such processes are employed for manufacturing optically cooperative surfaces vis-à-vis triangulation methods.

• Periodical: Key Engineering Materials (Volume 438)
• Pages: 123-129
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.438.123
• Online since: May 2010
• Authors: Friedrich Wilhelm Bach, Kai Möhwald, Martin Nicolaus, Eduard Reithmeier, Markus Kästner, Omar Abo-Namous
• Keywords: Optically Non-Cooperative Surface, Surface Metrology, Surface Technology

References

[1] Abo-Namous, O., Seewig, J., Kästner, M., Reithmeier, E. (2008): Fast method to measure optical cooperativity. Proc. DGaO, p. A16.

[2] Nicolaus, M.; Schäpers, M.: Grundlagen der Dünnschichttechnologie; in: Bach, F. -W.; Möhwald, K.; Laarmann, A.; Wenz, T. (Hrsg. ): Moderne Beschichtungsverfahren; WileyVCH Weinheim, (2004).

DOI: 10.1002/3527604278
