Solving Method of Contact Area for Logarithmic Spiral Bevel Gear

Abstract:

Introduces the solution method of logarithmic spiral bevel gear contact area, based on the logarithmic spiral bevel gear model divides any tooth, acquiring coordinate values, and then on the basis of Hertz contact theory, combined with elliptic functions, we found the solution method of a logarithmic spiral bevel gear contact area, and make judgment and shearing on the border of the contact area, which lays the foundation of solving the location, size and shape of the contact area on logarithmic spiral bevel gear.

• Periodical: Key Engineering Materials (Volumes 439-440)
• Pages: 590-593
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.439-440.590
• Online since: June 2010
• Authors: Qiang Li, He Wen, Hong Bo Yan
• Keywords: Contact Area, Logarithmic Spiral Bevel Gear, Point of Contact
