Prediction of Load Capacity Behavior of Multi-Stage Formed Construction Elements

Abstract:

The technologies for low-quantity production of sheet metal components and parts are applied mostly for thin single metal sheets. However, such technologies could also be applied as an additional procedure in multi-layer construction element production. Such individually produced construction elements must correspond to required standards, which are usually applied in serial production. Due to the immense testing work expected by custom-made production, it is reasonable to develop a methodology that would be capable of predicting the required results of an individually designed and produced construction block quickly, effectively and with minimal costs. In this investigation, a method of predicting the load capacity behavior of individual construction elements performed by incremental forming as an additional technology in multi-layer construction element production is presented. Special attention is dedicated to the definition of finite element model of a standardized four-point bending test and its correlation to real experimental results.

• Periodical: Key Engineering Materials (Volume 443)
• Pages: 195-200
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.443.195
• Online since: June 2010
• Authors: Aleš Petek, Karl Kuzman, Franc Resman, Boris Jerman, Viktor Zaletelj
• Keywords: Finite Element Model (FEM), Incremental Forming, Load Capacity, Multi-Layer Elements

References

[1] J. Jeswiet, F. Micari, G. Hirt, A. Bramley, J. Duflou and J. Allwood: CIRP Annals, vol. 54/2, (2005), p.623.

DOI: 10.1016/s0007-8506(07)60021-3

[2] A. Petek, V. Zaletelj and K. Kuzman: Journal of Mechanical Engineering, no. 7-8, vol. 55, (2009), p.423.

[3] J.M. Davis: Lightweight sandwich construction, MPG Books Ltd, Bodmin, Cornwall, (2001).

[4] A. Petek: The definition of stable technological window by incremental sheet metal forming, PhD Thesis, University of Ljubljana, (2009).

[5] A. Petek, B. Podgornik, K. Kuzman, M. Čekada, W. Waldhauser and J. Vižintin: Journal of Mechanical Engineering, vol. 54/4, (2008), p.266.

[6] J. M. Davies: Lightweight sandwich construction, Malden, MA, Blackwell Science, (2001).
