Prediction of Hypoeutectic Gray Iron Microstructure during Solidification and Solid Transformation Using Simple Fourier Model

Abstract:

Phases’ evolution during the solidification of a hypoeutectic 3.92% C-equivalence cast iron was modelled by considering the cooling history of the alloy from the melt, thus including both solidification and solid state transformations. Simple Fourier model was used to combine macroscopic heat flow and microscopic kinetics for phase evolution. Different cooling rates were obtained by casting cylinders and stepped plates. Measured number of primary austenitic nuclei, eutectic cells and volume fraction of phases during solidification (graphite, a-ferrite, pearlite and cementite), are correlated with the cooling rate. Growth rate constants for primary austenite, are found to be  = 8.7E-7, and n = 2.3. Growth rate constants for primary graphite (types A, B, and C), are found to be  =5.7E-7, and n = 2. The model matches with the experimental work where the error percent of modelling volume fractions of pearlite, graphite, ferrite and cementite ranges between 0.2 and 1.5%.

• Periodical: Key Engineering Materials (Volume 457)
• Pages: 293-298
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.457.293
• Online since: December 2010
• Authors: Mohamed A. Taha, Nahed A. El Mahallawy, Ahmed M. El-Sabbagh, Talat El-Benawy, Hasan F. Hadla
• Keywords: Heat Flow, Hypoeutectic Cast Iron, Kinetic, Phase Transformation, Solid State Transformation, Solidification

References

[1] D.M. Stefanescu, Materials Science and Engineering A 413-414 (2005), p.322.

[2] B. Lux, in: H.D. Merchant (Ed. ), Recent Research on Cast Iron, Gordon&Breach, NewYork (1968), p.241.

[3] D.M. Stefanescu and C.S. Kanetkar: AFS Trans., Vol. 95 (1987), p.139.

[4] G. Lesoult, M. castro and J. Lacaze, Model. Cast. Weld. adv. Solid. Process. VIII, San Diego (1998), p.479.

[5] D. Banerjee and D. stefanescu, AFS Trans., V. 104 (1991), p.747.

[6] W. Kurz and D. Fisher, TTPAedermannsdorf, Switzerland (1984).

[7] H. Fredriksson, J. Thorgrimsson and I. Svensson, KTH Fack, S-100 44 Stockholm, Sweeden, E-MRS-Strasbourg (1986).

[8] K. Su, I. Ohnaka and I. Yaunauchi and T. Fukusako, Physical metallurgy of cast iron, H. Fridriksson and M. Hillert, Ed., North Holland (1984), p.181.

[9] J. Hunt, Mater. Sci. Eng., Vol 65 (1984), p.75.

[10] H. Hadla, M. Sc. Thesis, Ain Shams university, Cairo (1997).

[11] M. Taha ,N. El-Mahallawy, T. El-Benawy and H. Hadla, Int. J. Cast Metals Res., 12 (1999), p.93.

DOI: 10.1080/13640461.1999.11819347

[12] S.K. Shaha and M.M. Haque, Am. J. Applied Sci., 7 no. 6 (2010), p.795.

[13] R. Hammouda, Ph.D. Thesis, ain Shams University, Cairo, Egypt (1998).

[14] M. Taha, N. El-Mahallawy, A. El-Sabbagh, Mater. Sci. Technol. (25), No. 5, (2009), p.670.

[15] R. Poirier and E. J. Poirier: Heat transfer fundamentals for metal casting, ed (1994), Warrendale, TMS.

[16] J. Thorgrimsson, Ph.D. Thesis, RIT, Stockholm, Sweeden (1986).

[17] H. Fredriksson, J. Thorgrimsson and I. Svensson in H. Fredriksson (ed. ), State of the art of computer simulation of casting and solidification processes, Les Ulis, Les Edition de Physique (1986), p.267.

[18] D. Stefanescu, S. Trufinescu and Z. Metalkde, Journal of Metallurgy, 41 (1989) p.22.

[19] L. Nastac and D. Stefanescu, ASME HTD-218/AMD, V. 139-27-34.

[20] H. Fredriksson and I. Svensson, The physical metallurgy of cast iron, Material research society, symposia proceedings, Vol 34, Stockholm, Elsevier science publishing Co., Inc., New York (1984), p.273.

[21] D.A. Porter and K.E. Easterling, Phase Transformations in Metals and Alloys, Van Nostrand, (1981).

[22] W. F. Lange and H. I. Aaronson, Metall. and Mater. Trans. A, V10, No. 12 (1979), 1951-(1952).

[23] H. Tian and D. Stefanescu, Conference: Model. Cast. Weld. adv. Solid. Process. VI, Florida (1993), p.639.

[24] M. A. Taha, N. A. El-Mahallawy, A. M. El-Sabbagh, Mater. Sci. Technol., Vol. 25(5) (2009), p.670.

[25] E. Fras, M. Gorny and H. F. Lopez, Metallurgical and Materials Transactions A, V36A (2005), p.3075.

[26] E. Fras, M. Gorny and H. F. Lopez, Metallurgical and Materials Transactions A, V36A (2005), p.3093 Fig. 11: Vf of a-Ferrite b-Pearlite c-Carbide d-Graphite (X-Position, Y-Height) for step sample.
