Research on Control System for the Automation Process of X-Cor Sandwich Structure Material

Abstract:

To realize the automation process for Pin implanting of X-cor sandwich structure, a hardware architecture of CNC based on open control system was proposed in which a Programmable Multi-axes Controller (PMAC) was adopted as the key unit for motion control and the accessory card for on-off control. The time based control mode is applied to realize synchronization of motion control and on-off control and to improve the real-time effort of the main tasks that closely related to the Pin implanting process. In addition, the device driver for PMAC, a user graphical interface as well as numerical control program interpretation module were also designed and the whole system is applied to the core material manufacturing process of X-cor sandwich structure.

• Periodical: Key Engineering Materials (Volume 464)
• Pages: 167-170
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.464.167
• Online since: January 2011
• Authors: Lin Liu, Chao Liang Lai, Yong Li, Jun Xiao
• Keywords: Motion Control, On-Off Control, Open CNC System, Pin Implanting, X-Cor

References

[1] K.T. O'Brien, I.L. Paris: Compos Struct Vol. 57(2002), p.189–204.

[2] U.K. Vaidya, M.V. Kamath, M.V. Hosur, A. Haque, S. Jeelani: Am Soc Mech Engnr, Mater Div (Publ) MD (1999).

[3] T. Carstensen, D. Cournoyer, E. Kunkel: X-Cor advanced sandwich core material[R]. In: Pro- ceedings of the 33rd international SAMPE technical conference, Seattle, WA; November (2001).

[4] Delta Tau Data Systems, Inc. PMAC user's manual. USA: Delta Tau Data System Inc, (1998).

[5] Delta Tau Data Systems, Inc. PMAC hardware manual PMAC2A-PC/104. USA: Delta Tau Data System Inc, (2003).
