Composition and Microstructure of Laser Cladding of 316 Stainless Steel

Abstract:

Laser Metal Deposition Shaping (LMDS) is a Rapid Manufacturing (RM) process that can be classified under the area of layered manufacturing techniques, where parts are built in layers. Parts of any complexity can be built directly from the 3D CAD model without much human intervention and requires minimum post-processing. In fact, LMDS technique can be recognized as multilayer laser cladding. Accordingly, it is necessary to perform the elementary laser cladding experiments with common metal powder so as to better understand the LMDS process. Then the characteristics of microstructure, composition and phase of as-deposited clads were analyzed through SEM and XRD, as well as relative model. The results prove that the microstructure of 316 stainless steel deposits is composed of the slender dendrites growing epitaxially from the substrate, and the composition is uniform without obvious segregation. Besides, it can be deduced from XRD diagram that the microstructure is composed of mono-phase γ.

• Periodical: Key Engineering Materials (Volumes 467-469)
• Pages: 2054-2059
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.467-469.2054
• Online since: February 2011
• Authors: Kai Zhang, Miao Yan Li, Xin Min Zhang
• Keywords: 316 Stainless Steel, Columnar Grains, Composition, Directional Solidification, Equiaxed Grain, Laser Cladding, Laser Metal Deposition Shaping (LMDS), Microstructure

References

[1] Wen Guo. Microstructural design of mechanical properties for laser-fabricated stainless steel parts. Dissertation for the Doctoral Degree. University of Central Florida. (2000).

[2] Kai Zhang, Weijun Liu, Xiaofeng Shang. Research on the processing experiments of laser metal deposition shaping. Optics & Laser Technology, 2007, 39(3): 549-557.

DOI: 10.1016/j.optlastec.2005.10.009

[3] Yanmin Li. Research on technical characters and microstructure of laser solid forming. Ph.D. dissertation, Northwestern Polytechnical University, 2001. (in Chinese).

[4] Liping Feng. Research on laser multi-layer cladding directional solidification. Ph.D. dissertation, Northwestern Polytechnical University, 2002. (in Chinese).

[5] Xin Lin, Haiou Yang, Jing Chen, Weidong Huang. Microstructure evolution of 316L stainless steel during laser rapid forming. Acta Metallurgica Sinica, 2006, 42(4): 361-368. (in Chinese).

DOI: 10.3724/sp.j.1037.2009.00192

[6] M. Gäumann, R. Trivedi, W. Kurz. Nucleation ahead of the advancing interface in directional solidification. Materials Science and Engineering A, 1997, 226-228: 763-769.

DOI: 10.1016/s0921-5093(97)80081-0

[7] M. Gäumann, S. Henry, F. Cléton, J. D. Wagnière, W. Kurz. Epitaxial laser metal forming: analysis of microstructure formation. Materials Science and Engineering A, 1999, 271(1-2): 232-241.

DOI: 10.1016/s0921-5093(99)00202-6

[8] J.W. Elmer, S.M. Allen, T.W. Eagar. Microstructure development during solidification of stainless steel alloys. Metallurgical and Materials Transactions A, 1989, 20(10): 2117-2131.

DOI: 10.1007/bf02650298
