Application and Research of Virtual Design for Superfine Wood Powder Pulverizer with Multi-Granularity

Abstract:

Processing technologies of superfine wood powder is a new field for wood the industry, while a new research direction is added for the wood industry. Grinding equipments for superfine wood powder is one key device for superfine wood powder production, and it plays an important role during processing superfine wood powder. Cutting and grinding methods with both semi-enclosed and two-cycle characteristics are used, there are three kinds of screen with various specifications inside the grinding room, and three kind of wood powder with different granularity requirements. Virtual reality technology is introduced into the wood powder pulverizer with multi-granularity designed, and both three-dimensional model of wood powder pulverizer with multi-granularity and the visual system for enhanced wood pulverizer are built. Virtual design technology can not only reduce product development cost greatly for the wood powder pulverizer but also shorten product development cycle for the wood powder pulverizer greatly, and there has vital significance to save manufacture cost.

• Periodical: Key Engineering Materials (Volumes 467-469)
• Pages: 2109-2112
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.467-469.2109
• Online since: February 2011
• Authors: Lan Yu Yang, Ying Li
• Keywords: Electric Main Spindle, Superfine Wood Powder, VR, Wood Pulverizer

References

[1] Lanyu Yang and Yan Ma. Present situations of domestic and foreign nanometer wood powder decomposition fundamental research[J]. Forestry machineries and woodworking equipment, 2007. 04: 9-11.

[2] Lanyu Yang and Yan Ma. Research on Superfine Wood Powder Disintegrator with Multi-granularity Used in Power Generation . Key Engineering Materials, 2009. 09: 505-507.

DOI: 10.4028/www.scientific.net/kem.419-420.505

[3] Lanyu Yang and Yan Ma. Research on article characteristics of cellulosine using in generation based on two-phase flow of the gas and solid. Advanced Engineering Materials, 2009. 11: 405-408.

[4] Lanyu Yang and Ya Ma. Pulverization theory for the cellulosine used in power generation and design of grinding device[J]. Machinery Design & Manufacture, 2009. 06: 150-152.

[5] Lanyu Yang and Ya Ma. Study on the raw material of wood flour in power generation and design theory of grinding equipment[J]. Journal of Anhui Agricultural Science, 2008. 20: 8640-8641. Acknowledgment Project supported by the Tianyin Plan Item of Mechanical-electro Union Technology Research Center for Changshu Institute of Technology.
