Displacement Analysis of the 3SPS-3CCS Mechanism Based on Hyper-Chaotic Newton-Downhill Method

Abstract:

The forward displacement analysis of parallel mechanism is attributed to find the solutions of complicated nonlinear equations and it is a very difficult process. Taking chaotic sequences as the initial values of Newton-downhill method, we can find all the solutions of equations quickly. Making use of existing chaos system and discovering new chaos system to generate chaotic sequences with good properties is the key to the Newton-downhill method based on Chaos sequences. Based on utilizing hyper-chaotic Hénon mapping to obtain initial points, a new method of finding all real number solutions of the nonlinear questions is proposed. Using cosine matrix method, the author established the mathematical model of forward displacement for the generalized 3SPS-3CCS parallel robot mechanism and a numerical example is given. Compared to the quaternion method building mathematical model, the result shows cosine matrix method building mathematical model and hyper-chaotic Newton-downhill method finding solution is brief and high calculation efficiency as the calculation is done in real number range. The proposed method has universality which can be used in forward displacement of other parallel mechanism.

• Periodical: Key Engineering Materials (Volumes 467-469)
• Pages: 401-406
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.467-469.401
• Online since: February 2011
• Authors: You Xin Luo, Xiao Yi Che, Bin Zeng
• Keywords: 3SPS-3CCS Parallel Mechanism, Cosine Matrix Method, Forward Displacement Analysis, Hyper-Chaotic Sequences, Nonlinear Equation

References

[1] F. WEN, C.G. LIANG, Q. Z. LIAO：China Mechanical Engineering, Vol. 10, No. 9 (1999), pp.1011-1013.

[2] RAGHAVAN M: ASME J. Mech. Des., Vol. 1l5, No. 1(1993), pp.227-282.

[3] SREENIVASAN S NANUA P: The 22nd Biennial Mechanisms Conference, Scottsdale, New York: ASME, pp.99-106(1992).

[4] A. X. LIU, T. L. YANG: Chinese Mechanical Science and Technology, Vol. l5, No. 4 (1996), pp.543-546.

[5] Wampler C W: Mechanism and Machine Theory, Vol. 31, No. 3(1996), pp.331-337.

[6] Lee T Y，Shim J K: Mechanism and Machine Theory, Vol. 36, No. 5(2001), pp.1073-1085.

[7] Y. X. LUO, D. Z. LI: Journal of Chinese Engineering Design, Vol. 10, No. 2 (2003), pp.95-101.

[8] X. S. GAO, Q. Z. LIAO: China Patent: 200410073712. 2, 2004-10-07.

[9] X. S. GAO,L. L. DE,Q. Z. LIAO, et a1: IEEETrans. Robotics, Vol. 2l, No. 2(2005), p. 14l-l51.

[10] X.G. HUANG,Q. Z. LIAO,S. M. WEI, et al: Journal of Beijing University of Posts and Tele., Vol. 30, No. 3(2007), pp.15-18, 31.

[11] X.G. HUANG ,Q. Z. LIAO, D.L. LI: Chinese Journal of Mechanical Engineering, Vol. 43, No. 5(2007), pp.8-13.

[12] Edward Ott. Chaos in Dynamical Systems (The Press of the University of Cambridge, Cambridge, 2002).

[13] Y. X. LUO: Machine design and research, Vol., 21, No. 5(2005), pp.19-22.

[14] Y. X. LUO: The International Conference on Mechanical Transmissions, Chongqing, China, pp.102-105(2006).

[15] Y. X. LUO, H.X. GUO: Journal of Harbin Institue of Tecchnology, Vol. 14, No. 1(2007), pp.13-17.

[16] Y.X. LUO, D. G. LIAO: Journal of Chinese Mechanical Transmission, Vol. 31, No. 1(2007), pp.28-30.

[17] Y. X. LUO, X. F. LI, L.L. LUO: Chinese Machine Design and Research, Vol. 23, No. 2(2007), pp.37-39.

[18] Youxin LUO, Xianfeng FAN, Dazhi LI, Xiao WU: Journal of Mechanical Engineering, Vol54 , No. 5, (2008), pp.372-378.

[19] Hendrik Richter.: International Journal of Bifurcation and Chaos, Vol. 12(2002), pp.1371-1381.

[20] Youxin Luo: ICIRA 2009, LNAI 5928, p.1224–1229.

[21] G. CUN, Wang Z.L. MATLAB program assembly (Electronic Industrial Press, Beijing 2008).
