Modelling of Fine Blanking Process of the Aluminium Sheets

Abstract:

The required technological quality of the blanked products can be achieved through operations of fine blanking. This allows for obtaining products with improved dimensional accuracy and good quality cut-surface. In order to cut products from soft materials, including aluminium and its alloys, the methods of fine blanking with upsetting and fine blanking with reduced clearance are typically employed. The study presents the results of numerical modelling of the fine blanking process for a disk made of 1-millimetre sheet aluminium EN AW-1070A. The goal of the numerical simulations was to evaluate the effect of clearance between blanking die and the punch, and the impact of V-ring indenter on stress and strain distribution in the shearing zone.

• Periodical: Key Engineering Materials (Volume 473)
• Pages: 290-297
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.473.290
• Online since: March 2011
• Authors: Wojciech Wieckowski, Piotr Lacki, Janina Adamus
• Keywords: Aluminum Sheet, Fine Blanking, Numerical Simulation

References

[1] Z. Polański: Blanking (in Polish: Wykrawanie), (WNT, Warsaw-Poland, 1978).

[2] T.C. Lee, L.C. Chan and B.J. Wu: J. Mater. Process. Technol. Vol. 48 (1995), p.105.

[3] T.C. Lee, L.C. Chan and P.F. Zheng: J. Mater. Process. Technol. Vol. 63 (1997), p.744.

[4] J. Adamus: Key Engineering Materials Vol. 344 (2007), p.185.

[5] J. Adamus and P. Lacki: Hutnik – Wiadomości Hutnicze (in Polish) Vol. 76/8 (2009), p.552.

[6] Z.H. Chen, C.Y. Tang, T.C. Lee and L.C. Chan: Int. J. Mech. Sci. Vol. 44 (2002), p.1309.

[7] W.F. Fan and J.H. Li: Mat. Sci. Eng. A Vol. 499 (2009), p.200.

[8] G. Fang, P. Zeng and L. Lou: J. Mater. Process. Technol. Vol. 122 (2002), p.249.

[9] R. Hambli: Int. J. Mech. Sci. Vol. 43 (2001), p.2769.

[10] R. Hambli: J. Mater. Process. Technol. Vol. 141 (2003), p.234.

[11] S. Kut: The influence of some parameters on quality of the fine blanked products (in Polish), (Oficyna Wyd. Politechniki Rzeszowskiej, Rzeszów-Poland, 2006).

[12] T. Sutasn and J. Masahiko: Key Engineering Materials Vol. 410-411 (2009), p.305.

[13] S.K. Maiti, A.A. Ambekar, U.P. Singh, P.P. Date and K. Narasimhan: J. Mater. Process. Technol. Vol. 102 (2000), p.249.

[14] N. Hatanaka, K. Yamaguchi and N. Takakura: J. Mater. Process. Technol. Vol. 139 (2003), p.64.

[15] M. Jr. Vaz and J. D. Bressan: J. Mater. Process. Technol. Vol. 125-126 (2002), p.206.

[16] N. Mole and B. Štok: Int. J. Mater. Form. Vol. 2/1 (2009), p.551.

[17] T.S. Kwak, Y.J. Kim, M.K. Seo and W.B. Bae: J. Mater. Process. Technol., Vol. 143-144 (2003), p.656.

[18] A.M. Goijaerts, Y.W. Stegeman, L.E. Govaert, D. Brokken, W.A.M. Brekelmans and F.P.T. Baaijens: J. Mater. Process. Technol. Vol. 103 (2000), p.44.

DOI: 10.1016/s0924-0136(00)00417-9

[19] X. Shuqin, M. Hoogen, T. Pyttel and H. Hoffmann: J. Mater. Process. Technol. Vol. 122 (2002), p.338.

[20] ADINA System v. 8. 3. Theory and Modelling Guide, Vol. I. ADINA R&D, Inc. (2005).

[21] R. Hambli and M. Reszka: Int. J. of Mechanical Sciences Vol. 44 (2002), p.1349.

[22] M. Farzin, H.R. Javani, M. Mashayekhi and R. Hambli: J. Mater. Process. Technol. Vol. 177 (2006), p.287.

[23] W.F. Fan, J.H. Li: Mat. Sci. Eng. A Vol. 499 (2009), p.248.

[24] F. Faura, A. Garcia and M. Estrems: J. Mater. Process. Technol. Vol. 80-81 (1998), p.121.

[25] K.H. Shim, S.K. Lee, B.S. Kang and S.M. Hwang: J. Mater. Process. Technol. Vol. 155-156 (2004), p. (1935).
