Investigation on the Effect of Pulsating Pressure on Tube-Hydroforming Process

Abstract:

Tube hydroforming process is one of the metal forming processes which uses internal pressure and axial feeding simultaneously to form a tube into the die cavity shape. This process has some advantages such as weight reduction, more strength and better integration of produced parts. In this study, T-shape tube hydroforming was analyzed by experimental and finite element methods. In Experimental method the pulsating pressure technique without counterpunch was used; so that the internal pressure was increased up to a maximum, the axial feeding was then stopped. Consequently, the pressure decreased to a minimum. The sequence was repeated until the part formed to its final shape. The finite element model was also established to compare the experimental results with the FE model. It is shown that the pulsating pressure improves the process in terms of maximum protrusion height obtained. Counterpunch was eliminated as being unnecessary. The results of simulation including thickness distribution and protrusion height were compared to the part produced experimentally. The result of modeling is in good agreement with the experiment. The paper describes the methodology and gives the results of both experiment and modeling.

• Periodical: Key Engineering Materials (Volume 473)
• Pages: 618-623
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.473.618
• Online since: March 2011
• Authors: Khalil Khalili, Seyed Yousef Ahmadi-Brooghani, Amir Ashrafi
• Keywords: Protrusion Height, Pulsating Pressure Hydroforming, Tube Hydro Forming, Wall Thickness

References

[1] Mori, K., Maeno, T., and Maki, S. Int. J. Mach. Tools Manuf., 2007, 47, 978–984.

[2] Mori, K., Patwari, A. U., and Maki, S. Ann. CIRP, 2004, 53(1), 215–218.

[3] Loh-Mousavi, M., Mori, K., Hayashi, K., Maki, S., and Bakhshi, M. Key Engng Mater., 2007, 340, 353–358.

DOI: 10.4028/www.scientific.net/kem.340-341.353

[4] Hama, T., Asakawa, M., Fukiharu, H., and Makinouchi, A. ISIJ Int., 2004, 44(1), 123–128.

DOI: 10.2355/isijinternational.44.123

[5] Loh-Mousavi, M., Mori, K., Hayashi, K., and Bakhshi-Jooybari, M. Key Engng Mater. 2007, 344, 461–467.

[6] M. Loh-Mousavi, M. Bakhshi, K. Mori, T. Maeno, M. Farzin, and S. J, Iranian Journal of Science & Technology, Transaction B, Engineering, Vol. 32, No. B6, pp.611-618.

[7] Mori, K., Maeno, T., Bakhshi-Jooybari, M., and Maki, S. Measurement of friction force in free bulging pulsating hydroforming of tubes. In Advanced Technology of Plasticity (Ed. P. F. Bariani), 2005 (Edizioni Progetto Padova, Padova) CD-ROM.

[8] M Loh-Mousavi, M Bakhshi-Jooybari, K-I Mori, and K Hyashi, Proc. IMechE Vol. 222 (2008).
