Rolling Bearing Finite Element Contact Analysis and Lectotype Design for Lunar Rover Wheel-Legged Mechanism

Abstract:

Taking the wheel-legged lunar rover based on double-half-revolution mechanism as a research object, this paper has made a dynamics simulation for the simplified virtual prototype model of lunar rover under several typical road conditions, with the purpose of obtaining the load applied on each bearing of lunar rover wheel-legged mechanism. On the basis of simulation analysis, static contact analysis for the wheel-leg rolling bearing was made by the finite element analysis software ANSYS. Through the finite element analysis for the rolling bearing, the maximum contact stress and deformation of the rolling body sustained the maximum force were obtained. The results will provide the new analytical method and basis for the optimization and lectotype design of the lunar rover wheel-leg rolling bearing.

• Periodical: Key Engineering Materials (Volumes 474-476)
• Pages: 748-753
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.474-476.748
• Online since: April 2011
• Authors: Yong Ming Wang, Tong Hua Fan, Xiao Liu Yu
• Keywords: Dynamic Simulation, Finite Element Analysis (FEA), Lectotype Design, Lunar Rover, Rolling Bearing

References

[1] M. Chacin and K. Yoshida. Evolving legged rovers for minor body exploration missions. In 1st IEEE/RAS-EMBS International Conference on Biomedical Robotics and Biomechatronics, 2006, BioRob 2006, Feb 20-22 2006, Pisa, Italy, 2006, pp.170-175.

DOI: 10.1109/biorob.2006.1639079

[2] Weiyan Shang, Shunming Li, Faju Qiu, et al. Structure Design and Analysis of New-style Four Leg Wheeled Lunar Rover. Journal of Wuhan University of Technology, Vol. 32, 2008(5), pp.822-825.

[3] Wang P F, Huang B, Sun L N. Walking Research on Multi motion Mode Quadruped Bionic Robot Based on Moving ZMP. In: Proc. of the 2005 IEEE International Conference on Mechatronics &Automation, Vol. 4, Niagara Falls, Canada, 2005, p.1935-(1940).

DOI: 10.1109/icma.2005.1626858

[4] Yongming Wang, Xiaoliu Yu, Wencheng Tang. A New-type Wheel-legged Lunar Rover and its Mobile Performance Analysis. In: the 2009 International Conference on Mechanical and Electrical Technology, ASME Press, New York, USA, 2009, pp.31-36.

DOI: 10.1115/1.802946.paper6

[5] Xiaoliu Yu, Hui Luo, Wei Xia. A study on the mobile system of lunar rover and its undulation based on semi-turning mechanism. Machine Design, Vol. 25, 2008 (11), pp.21-23.

[6] Yongming Wang, Xiaoliu Yu, Ronghai Chi, Wencheng Tang. Obstacle-climbing Performance Simulation Analysis of Wheel-legged Rover. The 2nd International Conference on Computer Engineering and Technology (ICCET 2010), IEEE Press, VOL. 1, 16-18 April 2010, Chengdu, China, pp.74-79.

DOI: 10.1109/iccet.2010.5486293

[7] Shuguang Gong. ANSYS Engineering Application Examples Analysis. Beijing: Mechanical Industry Press, (2003).
