Collision-Free Tool Path Generation for Five-Axis High Speed Machining

Abstract:

Collision detection is a critical problem in five-axis high speed machining. Using a combination of process simulation and collision detection based on image analysis, a rapid detection approach is developed. The geometric model provides the cut geometry for the collision detection and records a dynamic geometric information for in-process workpiece. For the precise collision detection, a strategy of image analysis method is developed in order to make the approach efficient and maintian a high detection precision. An example of five-axis machining propeller is studied to demonstrate the proposed approach. It has shown that the collision detection task can be achieved with a near real-time performance.

• Periodical: Key Engineering Materials (Volumes 474-476)
• Pages: 961-966
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.474-476.961
• Online since: April 2011
• Authors: Li Qiang Zhang, Min Yue
• Keywords: Collision Detection, Five-Axis, Geometric Simulation, Toolpath Correction

References

[1] Z.Z. Li and D.C. Liu: Journal of Materials Processing Technology Vol. 138(2) (2003), p.513.

[2] B.U. Guzel and I. Lazoglu: International Journal of Machine Tools and Manufacture Vol. 44 (21) (2004), p.21.

[3] L.Q. Zhang: International Journal of Advanced Manufacturing Technology Vol. 40(11) (2009), p.1191.
