Feedback Control of a Flexible Micro-Displacement Manipulator

Abstract:

Micro-displacement manipulator consists of piezoelectric actuator and flexure hinge is being widely used in precision positioning technology for its high resolution of displacement, high stiffness and fast frequency response. However, the hysteresis nonlinearity of actuator and vibration limited its control accuracy. In order to improve the positioning precision, the relationship between input voltage and output displacement was studied, the hysteresis nonlinearity was described by mathematical method, and a closed-loop controller was proposed to control the hysteresis and vibration. Experiment results revealed the proposed closed-loop controller can enhance the control precision of micro-displacement manipulator.

• Periodical: Key Engineering Materials (Volumes 480-481)
• Pages: 1167-1172
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.480-481.1167
• Online since: June 2011
• Authors: Hua Wei Ji, Yong Qing Wen, Chen Ming Fu
• Keywords: Feedback Control, Flexure Hinge, Manipulator, Micro-Displacement

References

[1] Smith, S.T. Flexures: elements of elastic mechanisms. Gordon and Breach Science Publisher, (2000).

[2] H. Richter, E.A. Misawa, D.A. Lucca etc, Modeling nonlinear behavior in piezoelectric actuator, Precision Engineering, Vol 25, pp.128-137, (2001).

DOI: 10.1016/s0141-6359(00)00067-2

[3] Goldfarb, M. and N. Celanovic. Modeling piezoelectric stack actuators for control of micromanipulation. IEEE Control Systems Magazine, 1997, 17(3): pp.69-79.

DOI: 10.1109/37.588158

[4] E. SCIRE, F. and E.C. TEAGUE. Piezodriven 50-μm range stage with subnanometer resolution. Review of Scientific Instruments, 1978. 49(12): pp.1735-1740.

DOI: 10.1063/1.1135327

[5] Gao, P., S. Swei, and Z. Yuan. A new piezodriven precision micropositioning stage utilizing flexure hinges. Nanotechnology, 1999. 10: pp.394-398.

DOI: 10.1088/0957-4484/10/4/306

[6] Jih-Lian Haa, Ying-Shieh Kung. Optimal design of a micro-positioning Scott-Russell mechanism by Taguchi method. Sensors and Actuators A 125 (2006) 565–572.

DOI: 10.1016/j.sna.2005.06.025

[7] Tan, U.X.; Win, T.L.; Ang, W.T. Modeling Piezoelectric Actuator Hysteresis with Singularity Free Prandtl-Ishlinskii Model . IEEE International Conference on Robotics and Biomimetics, 2006. ROBIO '06. 251 - 256.

DOI: 10.1109/robio.2006.340162

[8] Ping. Ge, Tracking control of a piezoceramic actuator, IEEE transactions on control systems technology, Vol 4, No. 3, pp.209-215, (1996).

DOI: 10.1109/87.491195

[9] Hao Jiang; Hongli Ji; Jinhao Qiu. A modified prandtl-ishlinskii model for modeling asymmetric hysteresis of piezoelectric actuators . IEEE Transactions on Ultrasonics, Ferroelectrics and Frequency Control, . 2010. 57(5): p.1200 – 1210.

DOI: 10.1109/tuffc.2010.1533

[10] Ping. Ge，M. Jouaneh. Modeling hysteresis in piezoceramic actuators. Precision Engineering, ，1995，Vol 17： 211-221.

DOI: 10.1016/0141-6359(95)00002-u
