Limiting Factors of Driving Hall Element by Pulsed Power Supply

Abstract:

The limiting facts of driving the Hall element by the pulsed power supply and sampling when the peak value coming are studied. The equivalent relation of temperature rising between the DC and pulsed power supply is given. When the electric field intensity inside the Hall element rises to about 1850V/cm, the linear relationship between the Hall output voltage and the input voltage will be affected by the decrease of the mobility. The thermal-power consumption almost does not affect the use of the Hall element. The above problem could be overcome by enlarging the die dimension.

• Periodical: Key Engineering Materials (Volumes 480-481)
• Pages: 786-789
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.480-481.786
• Online since: June 2011
• Authors: Xue Lei Chen
• Keywords: Hall Element, High Electric Field Effect, Pulse, Thermal Effect

References

[1] Y.R. Tu: Journal of Transducer Technology Vol. 18 (1999), p.5.

[2] J. Lenz: Proceedings of the IEEE, Vol. 78 (1990), 973-989.

[3] W.K. Lu, C.C. Zhu, J.A. Fang: Hall Device and Applied Circuit for Electronic Measurement (China Electric Power Press, Beijing 2005).

[4] R.S. Popovic, Z. Randjevoic, D. Manic: Sensors and Actuators A, Vol. 91 (2001), p.46.

[5] L.X. Ye: Semiconductor Physics (Higher Education Press, Beijing 2007).

[6] J.G. Ruch, W. Facett: Journal of Applied Physics Vol. 41 (1970), p.3843.

[7] K. Mitra: Journal of Heat Transfer Vol. 117 (1995), p.568.

[8] S. M Yang, W.Q. Tao: Heat Transfer (Higher Education Press, Beijing 1998).

[9] X.L. Chen: submitted to IEEE International Conference on Information and Education Technology (2011).
