Finite Element Analysis of Ti-6Al-4V Alloy Crater Geometry for EDM Based on a Single Discharge

Abstract:

Temperature theoretical model of Ti-6Al-4Valloy during electrical discharge machining (EDM) process is established in this paper. Based on finite element thermal analysis, the temperature field of EDM Ti-6Al-4V on a single discharge is simulated with the aid of ANSYS software. The results show that there is a high temperature distribution around the spark point while the thermal-affected zone is quite small. Additionally, the profiles of discharge crater geometry have been predicted and the relation between crater shape and parameters under different current and pulse duration are also explored.

• Periodical: Key Engineering Materials (Volume 487)
• Pages: 423-428
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.487.423
• Online since: July 2011
• Authors: Yan Wang, Jiu Hua Xu, Feng Gao
• Keywords: Discharge Crater, EDM, Single Discharge, Thermal Analysis, Ti-6Al-4V Alloy

References

[1] E.O. Ezugwu and Z.M. Wang: J. Material Process Technology Vol. 68 (1997), pp: 262–274.

[2] Ahmet Hascalık and Ulas Caydas: Applied Surface Science Vol. 253 (2007), pp: 9007–9016.

[3] C.H.C. Haron and A. Jawaid: J. Material Process Technology Vol. 166 (2005), pp: 188–192.

[4] H. -P. Schulze, R. Herms and H. Juhr: J. Material Process Technology Vol. 149(2004): 316-322.

[5] Vinod Yadav, Vijay K Jain and Prakash M Dixit: Int. J. Machine Tools Manufacture Vol. 42(2002), pp: 877-888.

[6] Shankar P, Jain V K and Sundarajan T: Machining Science and Technology Vol. 1 (1997), pp: 195-217.
