Research on the Ductile Chip Formation in Grinding of Brittle Materials

Abstract:

A theoretical discussion has been presented for the ductile chip formation in grinding of brittle materials. The single abrasive grit was dealt with a top-rounded cutter removing material of varying undeformed chip thickness. The force model in the chip formation zone was established. The stress analysis showed that larger compressive stress and shear stress can be generated in the chip formation zone, which shields the growth of pre-existing flaws in the material by suppressing the stress intensity factor. When the stress intensify factor is smaller than fracture toughness and the resolved shear stress exceeds the critical flow stress of the material, the ductile chip is formed. Experiments of monocrystal silicon grinding were conducted. The results show that the thrust force is much larger than the cutting force, which ensures the larger compressive stress in the chip formation zone and the formation of ductile chip.

• Periodical: Key Engineering Materials (Volume 487)
• Pages: 58-62
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.487.58
• Online since: July 2011
• Authors: Yun Feng Peng, Zhi Qiang Liang, Yong Bo Wu, Yin Biao Guo, T. Jiang, X. Chen
• Keywords: Brittle Material, Chip Formation Zone, Compressive Stress, Ductile Chip, Grinding

References

[1] B. K. A. Ngoi and P. S. Sreejith: International Journal of Advanced Manufacturing Technology Vol. 16 (2000), pp: 547–550.

[2] D. J. Stephenson: Advances in Technology of Materials and Materials Processing Vol. 8(1) (2006), pp: 13-22.

[3] J. Yoshioka, K. Koizumi, M. Shimuzu, H. Yoshikawa, M. Miyasahita and A. Kanai: SME Technical Paper Vol. (1982), pp: MR82–930.

[4] S. B. Toh and R. McPherson: Fine Scale Abrasive Wear of Ceramics by a Plastic Cutting Process, Science of Hard Materials, Institute Physics Conference Series Vol. 75(9) 1986, pp: 856-871.

[5] T. Bifano, G. P. Blake, T. A. Dow and R. O. Scattergood: American Ceramic Society Bulletin Vol. 67(6) (1988), pp: 1038-1044.

[6] R. L. Hecker, S. Y. Liang and X. J. Wu et al.: The International Journal of Advanced Manufacturing Technology Vol. 33 (2007), pp: 449-459.

[7] K. Liu and X. P. Li: Journal of Materials Processing Technology Vol. 113 (2001), pp: 348-354.

[8] K. Liu and X. P. Li: Transactions of NAMRI/SME XXIX Vol. (2001), pp: 251-258.

[9] D. Broek: Elementary Engineering Fracture Mechanics (Martinus Nijihoff Publishers. The Hague Vol. (1984).

[10] K. Liu, X. P. Li and S. Y. Liang: International Journal of Advanced Manufacturing Technology Vol. 33 (2007), pp: 875-884.

[11] S. Venkatachalam: Predictive Modeling for Ductile Machining of Brittle Material( PHD thesis, Georgia Institute of Technology Vol. (2007).
