Modelling the Contact between the Rolling Elements and the Raceways of Bulky Slewing Bearings

Abstract:

In slewing bearings, a great number of contact pairs are present on the contact surfaces between the rolling elements and raceways of the bearing. Computations to determine the load of the individual rolling elements, taking into account the flexibility of the bearing ring, are most often carried out using the finite element method. Construction of a FEM full model of the bearing, taking into account the shape of the rolling elements and the determination of the contact problem for every rolling element, leads to a singularity of stiffness matrix, which in turn makes the problem impossible to solve. In FEM models the rolling elements are replaced by one-dimensional finite elements (linear elements) to simplify the computation procedure and to obtain an optimal time for computations. The methods of modelling the rolling elements in the slewing bearing, in which balls have been replaced by truss elements with a material non-linear characteristic located between the raceway centres of the curvatures in their axial section, are presented in the paper.

• Periodical: Key Engineering Materials (Volume 490)
• Pages: 166-178
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.490.166
• Online since: September 2011
• Authors: Marek Krynke, Ludwik Kania, Eugeniusz Mazanek
• Keywords: Contact Angle (CA), Contact Zone, Equivalent Characteristic of Truss Element, Finite Element Method (FEM), Load Distribution, Slewing Bearing

References

[1] T. Smolnicki, Physical aspects of coherence of large-size rolling bearings and deformable support structures, Wrocław: Wrocław University of Technology Publishing House, 2002 (in Polish).

[2] R. Kunc, I. Prebil, Numerical determination of carrying capacity of large rolling bearings, Journal of Materials Processing Technology, 155–156 (2004) 1696–1703.

DOI: 10.1016/j.jmatprotec.2004.04.125

[3] E. Mazanek, Constructional and strength problems of large-size rolling bearings, Monografie nr 105, Wydawnictwa Politechniki Częstochowskiej, Częstochowa 2005 (in Polish).

[4] J.I. Amasorrain, X. Sagartzazu, J. Damián, Load distribution in a four contact-point slewing bearing, Mechanism and Machine Theory, 38 (2003), 479-496.

DOI: 10.1016/s0094-114x(03)00003-x

[5] S. Zupan, I. Prebil, Carrying angle and carrying capacity of a large single row ball bearing as a function of geometry parameters of the rolling contact and the supporting structure stiffness, Mechanism and Machine Theory, 36 (2001), 10: 1087-1103.

DOI: 10.1016/s0094-114x(01)00044-1

[6] T. Smolnicki, E. Rusinski, Superelement-Based Modeling of Load Distribution in Large-Size Slewing Bearings, Journal of Mechanical Design, 129, (2007), 4: 459-463.

DOI: 10.1115/1.2437784

[7] L. Kania, Modelling of rollers in slewing bearing calculations with the use of finite elements, Mechanism and Machine Theory, 41 (2006), 11: 1359-1376.

DOI: 10.1016/j.mechmachtheory.2005.12.007

[8] L. Kania, Analysis of internal load of slewing bearings in respect of their load carrying capacity, Seria monografie nr 111, Wydawnictwa Politechniki Częstochowskiej, Częstochowa 2005 (in Polish).

[9] Z. Chaib, A. Daidie, A. Ghosn, 3D simplified finite elements analysis of load and contact angle in a slewing ball bearing, Journal of Mechanical Design, 130 (2008) 8: 082601 (8 pages).

DOI: 10.1115/1.2918915

[10] Z. Chaib, A. Daidié, D. Leray, Screw behavior in large diameter slewing bearing assemblies: numerical and experimental analyses, Int J Interact Des Manuf (2007) 1:21-31.

DOI: 10.1007/s12008-007-0003-7

[11] J. Brändlein, P. Eschmann, L. Hasbergen, K. Weigand, Ball and Roller Bearings: Theory, Design and Application, Willey, (1999).

[12] L. Kania, Substitute characteristics of the rollers in modelling ring roller bearings, Przegląd Mechaniczny, 57 (2003), 7-8: 35-40 (in Polish).

[13] ADINA, Theory and Modeling Guide, Volume 1: ADINA. ADINA R&D, Inc., Watertown 2007.

[14] L. Kania, M. Krynke, E. Mazanek: The variation of the contact angle in a flexible four – point slewing ball bearing, 24th Scientific Conference "Trends in The Development of Heavy Duty Machines", Zakopane 2008: 211–218 (in Polish).
