Numerical Simulation on Temperature Field in Multi-Layers Inside-Beam Powder Feeding when Laser Cladding

Abstract:

Numerical simulation of laser cladding is the main research topics for many universities and academes, but all researchers used the Gaussian laser light source. Due to using inside-beam powder feeding for laser cladding, the laser is dispersed by the cone-shaped mirror, and then be focused by the annular mirror, the laser can be assumed as the light source of uniform intensity.In this paper,the temperature of powder during landing selected as the initial conditions, and adopting the life-and-death unit method, the moving point heat source and the uniform heat source are realized. In the thickness direction, using the small melt layer stacking method, a finite element model has been established, and layer unit is acted layer by layer, then a virtual reality laser cladding manu-facturing process is simulated. Calculated results show that the surface temperature of the cladding layer depends on the laser scanning speed, powder feed rate, defocus distance. As cladding layers increases, due to the heat conduction into the base too late, bath temperature will gradually increase. The highest temperature is not at the laser beam, but at the later point of the laser beam. In the clad-ding process, the temperature cooling rate of the cladding layer in high temperature section is great, and in the low-temperature, cooling rate is relatively small. These conclusions are also similar with the normal laser cladding. Finally, some experiments validate the simulation results. The trends of simulating temperature are fit to the actual temperature, and the temperature gradient can also ex-plain the actual shape of cross-section.

• Periodical: Key Engineering Materials (Volume 499)
• Pages: 114-119
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.499.114
• Online since: January 2012
• Authors: Ming Di Wang, Shi Hong Shi, X.B. Liu, Cheng Fa Song, Li Ning Sun
• Keywords: Inside-Beam Laser, Multi-Layers Cladding, Numerical Simulation, Temperature Field

References

[1] S. Kumar, S. Roy: Computational Materials Science. Vol. 37(4) (2006) , pp.425-433.

[2] C.P. Paul, P. Ganesh, S.K. Mishra et al: Optics & Laser Technology. Vol. 39(4) (2007), pp.800-805.

[3] A. Plati J.C. Tan I.O. Golosnoy, et al: Advanced Engineering Materials Vol. 8(7)(2006), pp.619-624.

[4] D.D. GU, Y.F. SHEN, M.C. LIU, et al: Transactions of Nanjing University of Aeronautics & Astronautics. Vol. 21(3) (2004) , pp.225-233.

[5] M.D. Wang, S.H. Shi, and D.W. Zuo: Key Engineering Materials Vol. 426-427(2010), pp.151-155.

[6] L.K. Shi, S.Y. Gao and M.Z.X. et al: Metal Technology Vol. 42(5) (2006), pp.449-453.

[7] X.F. Wang, G.N. Chen and S.G. Hu. et al: China Laser. Vol. 31(12) (2004), pp.1518-1521.

[8] H.F. Guo, J.Z. Zhong and Zeng: Tool Engineering. Vol. 40(11) (2006), pp.13-18.

[9] M.D. Wang, S.H. Shi, and D.W. Zuo: Chinese Journal of Nanjing University of Aeronautics & Astronautics. Vol. 41(3) (2009), p.354~357.

[10] M.D. Wang, D.W. Zuo, M. Wang et al: International Conference on Advanced Design and Manufacturing (Sanya, China, January 14-16, 2008).
