A New Kind of Integrating Sphere Radiation Calibration System for Satellite Remote Sensors

Abstract:

A new kind of half integrating sphere radiation system that has the adjustable area of radiating surface in the 380nm-2500nm wave band is introduced in this paper. The opening diameter of the integrating sphere reaches to Φ600mm. Half Integrating sphere radiation system is mainly composed of a half sphere, extension part, cyclic annular baffles and other components. The diameter of half-integrating sphere is Φ1800mm. The radiance uniformity through opening reaches up to 98%. Systems can now be used for all types of large field of view of satellite remote sensor for the calibration of spectral radiance; in addition, it can also be applied for various types of light exposure calibration such as flash lamp and so on.

• Periodical: Key Engineering Materials (Volume 500)
• Pages: 569-573
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.500.569
• Online since: January 2012
• Authors: Ting Liang Guo, Guo Jin Feng, Yu Wang, Ying Wei He
• Keywords: Calibration, Integrating Sphere, Remote Sensor, Spectral Radiance

References

[1] D. Y. Yin, X. Feng, L. H. Zheng, J. W. Li, Y. M. Li, S. M. Zhang and Q. Feng, Stepping motors of COCTS on HaiYang-1 satellites, Journal of Astronautics 2009, vol. 30, pp.355-361.

[2] H. J. Wang, H. Y. Wang and S. F. Tang, Overall superiority of the optical remote sensor highlighted the feature of CBERS, Spacecraft Recovery & Remote Sensing , 2008, vol. 29, pp.7-11.

[3] D. Y. Chen and Y. L. Wu, Inter-calibration data processing of HJ-1 satellite CCD camera, Spacecraft Recovery & Remote Sensing 2007, vol. 28, pp.21-28.

[4] L. Fonseca, F. Ponzoni, R. Cartaxo, J. Epiphanio, and L. Miranda, Radiometric Quality Assessment of CBERS-2, Technical Report, Brazilian National Institute for Space Research-INPE, (2004).

[5] Y. Zeng, Y. F. Zhang, J. Y. Xu, and J. Yu, Analysis of Laboratory Radiometric Calibration Algorithm of CBERS-02 CCD camera, Spacecraft Recovery & Remote Sensing 2006, vol. 26, pp.41-45.

[6] G. Mckee, S. Pal, H. Seth, A. Bhardwaj and H. Sahoo, Design and characterization of a large area uniform radiance source for calibration of a remote sensing imaging system, Proc. SPIE 6677, 667706 , (2007).

DOI: 10.1117/12.732122

[7] L. Hanssen, and A. Prokhorov, Numerical modeling of an integrating sphere radiation source, Proc. SPIE 4775, 2003, pp.106-118.

[8] Carr, K.F., A Guide to Integrating Sphere Radiometry & Photometry, Labsphere Technical Guide, Labsphere Inc. (1997).

[9] J. Rice, and B. Johnson, NIST activities in support of space-based radiometric remote sensing, Proc SPIE 4450, 2001, pp.108-126.
