Material Parameter Identification from Machining Simulations Using Inverse Techniques

Abstract:

Machining is a complex process during which the material undergoes large deformations at high strain-rates with large variations in temperatures. One of the difficulties faced during the simulation of machining is that of determining appropriate material parameters which are valid for such large ranges of strains, strain-rates and temperatures. An inverse method of material parameter identification from machining simulations is proposed in this paper. An error function is defined that takes into account the chip overlap error and the cutting force difference at different frames of observation. The two components are suitably weighted so that the contribution of each is rendered almost equally. A two stage optimisation process is employed for the minimisation of the error function where the Levenberg-Marquardt algorithm is used in the first stage for faster convergence and the Downhill Simplex algorithm in the second stage in order to navigate through the noisy error landscape. A wide range of cutting conditions is used and the method is shown to work also for non-adiabatic simulations. However, the converged parameter sets are found to be non-unique.

• Periodical: Key Engineering Materials (Volumes 504-506)
• Pages: 1281-1286
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.504-506.1281
• Online since: February 2012
• Authors: Aviral Shrot, Martin Bäker
• Keywords: Inverse Method, Johnson-Cook Parameters, Machining Simulation, Parameter Identification

References

[1] P. Mathew, P. Oxley, Predicting the Effects of Very High Cutting Speeds on Cutting Forces, etc., CIRP Annals-Manufacturing Technology 31 (1) (1982) 49-52.

DOI: 10.1016/s0007-8506(07)63267-3

[2] G.R. Johnson, W.H. Cook, A constitutive model and data for metals subjected to large strains, high strain rates and high temperatures, in: 7th International Symposium on Ballistics (1983) 514-546.

[3] A. Shrot, M. Bäker, Determination of Johnson–Cook parameters from machining simulations, Comp. Mat. Sci., 52 (2012) 298-304.

DOI: 10.1016/j.commatsci.2011.07.035

[4] A. Shrot, M. Bäker, Johnson-Cook parameter identification from machining simulations using an inverse method, in: E. Oñate, D.R.J. Owen (Eds.), XI International Conference on Computational Plasticity. Fundamentals and Applications, Barcelona, 2011.

DOI: 10.4028/www.scientific.net/amr.223.277

[5] W. Press, S. Teukolsky, W. Vetterling, B. Flannery, Numerical recipes in Fortran; the art of scientific computing, Cambridge University Press, New York, 1993.

DOI: 10.1086/416228

[6] Dassault Systèmes, ABAQUS 6.9 Analysis User's Manual, USA, 2009.

[7] B. Taljat, B. Radhakrishnan, T. Zacharia, Numerical analysis of GTA welding process with emphasis on post-solidification phase transformation effects on residual stresses, Mat. Sci. Engg. A, 246 (1998) 45-54.

DOI: 10.1016/s0921-5093(97)00729-6

[8] R.C. Batra, C.H. Kim, Effect of viscoplastic flow rules on the initiation and growth of shear bands at high strain rates, J. Mech. Physics of Solids, 38 (1990) 859-874.

DOI: 10.1016/0022-5096(90)90043-4

[9] D.M. Goto, J.F. Bingert, S.R. Chen, G.T. Gray, R.K. Garrett, The mechanical threshold stress constitutive-strength model description of HY-100 steel, Met. Mat. Trans. A, 31A (2000) 1985-1996.

DOI: 10.1007/s11661-000-0226-8

[10] M. Galassi, J. Davies, J. Theiler, B. Gough, G. Jungman, M. Booth, F. Rossi, GNU Scientific Library Reference Manual, first ed., 2010.

[11] A. Shrot, M. Bäker, Is it possible to identify Johnson-Cook law parameters from machining simulations?, Int. J. Mat. Form., 3 (2010) 443-446.

DOI: 10.1007/s12289-010-0802-4

[12] A. Shrot, M. Bäker, Inverse Identification of Johnson-Cook Material Parameters from Machining Simulations, Adv. Mat. Research, 223 (2011), 277-285.

DOI: 10.4028/www.scientific.net/amr.223.277
